Service Manual Mitsubishi SL-Series diesel engines
Version 08/2004
AUTOMATIC GLOW SYSTEM
ENGLISH
ELECTRICAL SYSTEM
33.3 Glow plug relay specifications
(standard)
2
33.4 Glow plug inspection
Test for continuity between the terminal and body as
shown in the illustration. If no continuity, replace with
new one.
Figure 202 Glow plug relay
2. All specifications are subject to change without any prior
notice.
Part number MM431-28201
Rated voltage DC 12 V
Continuous rating 1 minute
Coil resistance 13 Ω
Operating temperature
range
–40°C to +100°C
(–40°F to +212°F)
Figure 203 Testing glow plug
Item Standard
Resistance 0.55 Ω

Mitsubishi S4L2 Specifications

General

Compression Ratio	22:1
Aspiration	Naturally Aspirated
Fuel System	Direct injection
Engine Model	S4L2
Starting System	Electric Starter
Cooling System	Water-cooled
Engine Type	4-stroke, water-cooled, diesel engine
Lubrication System	Forced lubrication
