Service Manual Mitsubishi SL-Series diesel engines
Version 08/2004
COMPONENT LOCATION
ENGLISH
GENERAL INFORMATION
2.4 Engine S4L-T/S4L2-T
RIGHT SIDE VIEW
Oil filler
Fuel injection nozzle
Fuel injection pump
Water pump
Oil filler
Crankshaft pulley
Dipstick
FRONT
Oil filter
Oil pressure switch
Air inlet cover
REAR
Thermostat
Hanger
Alternator
Fan
V-belt
Exhaust manifold
Starter
Oil pan
REARFRONT
Flywheel
LEFT SIDE VIEW
Oil drain plug
Hanger
Stop solenoid
Fuel filter
Air vent screw
Thermoswitch
Turbocharger
Flywheel housing

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Mitsubishi S4L2 and is the answer not in the manual?

Mitsubishi S4L2 Specifications

General IconGeneral
Compression Ratio22:1
AspirationNaturally Aspirated
Fuel SystemDirect injection
Engine ModelS4L2
Starting SystemElectric Starter
Cooling SystemWater-cooled
Engine Type4-stroke, water-cooled, diesel engine
Lubrication SystemForced lubrication
