8-17
Chapter 8 FUEL SYSTEM
Actuator - Remove and Inspect
Actuator spec
*Woodward ProAct actuator
Replace: Rubber cushion
Replace: Rubber cushion
Replace
2
1
3
Removing Sequence
1 Actuator 2 Plate 3 Actuator bracket
