Mitsubishi S6R Series

12-4
Chapter 12 AIR START SYSTEM
1.2 Air Pipe, Starter Valve and Distributor Valve - Inspect
Air Pipe, Starter Valve and Distributor Valve - Remove
A
A
Air direct starting spec
Replace: Gasket, O-ring
1
2
3
5
4
7
6
Removing Sequence
1 No.1 thru 6 pilot air pipes
2 Main air pipe
3 Main air pipe
4 Main air pipe
5 Oil pipe
6 Distributor
7 Startor valve
