6-16
Chapter 6 INSPECTION AND REPAIR OF BASIC ENGINE
3. Front Mechanism - Inspect and Repair
3.1 Damper - Inspect Visually
Check the damper for cracks around outer periphery, swell-
ing in end plate, silicone oil leakage, and discoloration and
separation of coating due to overheating. If any defect is
found, replace the damper with a new one.
Damper - Inspect Visually
3.2 Pulley - Inspect
Check the belt groove of pulley for wear.
(1) Check the sinkage of belt.
(2) Fit a new belt tightly in pulley groove.
(3) If the belt sinks 1.6 mm [0.063 in.] or more below pul-
ley rim, replace the pulley with a new one.
Pulley Wear - Inspect
1.6 mm [0.063 in.]
or less
To Next Page
