3-3
Chapter 3 SERVICE TOOLS
Chapter 3 SERVICE TOOLS
1. Special Tools
Maintenance
item
Tool name Part No. Illustration Usage
Basic engine Rocker bushing tool 37591-02600 Rocker bushing - replace
Bushing inside diam : ø36 × 40 mm
[1.38 ×1.57 in.]
Idler bushing puller 32591-02500 Idler bushing - replace
Bushing inside diam : ø50 × 55 mm
[1.97 × 2.17 in.]
Eye bolt 37591-02500 Main bearing cap - remove
Eye bolt 05930-00200 Gear case - lift
Eye bolt 45815-32301 Piston - lift
Eye nut 37591-02400 Cylinder head assembly - install/
remove
Front seal
Installer assembly
37591-05010 Front oil seal - install
Rear seal installer
assembly
37591-06010 Rear oil seal - install
To Next Page
