Mitsubishi S6R Series

1-7
Chapter 1 GENERAL
Engine Front View
Engine Rear View
Tension pulley
Engine coolant outlet
Thermostat case
Oil pan
Note: Configuration varies depending on the destination and specifications.
S6R-Y2PTAW
Water pump
Damper
Water pump
for air cooler cooling
Flywheel
Timing gear case
S6R-Y2PTAW
Note: Configuration varies depending on the destination and specifications.
Engine oil drain port
Rotation directionRotation direction
Rotation direction
