Mitsubishi S6R Series User Manual

No.2
INSPECTION RECORD SHEET
Approved by Checked by Measured by
Remark
Cylinder liner bore flange protrusion
CD
15
16
3
4
5
6
7
8
9
10
1
2
Item
Cylinder liner bore flange protrusion - measure
Item to be measured
A
Measured value
Item
No. B
Measuring location
Customer
Standard
Engine Model
Serial No.
0.16 to 0.24
[0.0063 to 0.0094]
S6R,S6R2
Cylinder liner
flange
protrusion
S12R,S16R
0.11 to 0.20
[0.0043 to 0.0079]
Standard
SR
Date
mm[in.]Unit
Average value
11
12
13
14
