Chapter 2 SERVICE DATA
Sea water pump for air cooler
Inside diameter of case bearing housing
ø90
[3.54]
89.9825 to 90.0175
[3.5426 to 3.5440]
Bearing
Outside
diameter
ø90
[3.54]
90.000 to 90.015
[3.5433 to 3.5439]
Inside
diameter
ø30
[1.18 in.]
29.990 to 30.000
[1.1807 to 1.1811]
ø40
[1.57]
39.988 to 40.000
[1.5743 to 1.5748]
Outside diameter of shaft fit to bearing
ø30
[1.18 in.]
30.002 to 30.018
[1.1812 to 1.1818]
ø40
[1.57]
40.002 to 40.018
[1.5743 to 1.5749]
Fan drive
Inside diameter of case bearing housing
ø100
[3.94]
99.987 to 100.022
[3.9365 to 3.9379]
ø110
[4.33]
109.987 to 110.022
[4.3302 to 4.3316]
Bearing
Outside
diameter
ø100
[3.94]
99.985 to 100.000
[3.9364 to 3.9370]
ø110
[4.33]
109.985 to 110.000
[4.3301 to 4.3307]
Inside
diameter
ø45 [1.77]
45.002 to 45.013
[1.7717 to 1.7722]
ø50 [1.97]
50.002 to 50.013
[1.9686 to 1.9690]
Outside diameter of shaft fit to bearing
ø45 [1.77]
44.988 to 45.000
[1.7712 to 1.7717]
ø50 [1.97]
49.988 to 50.000
[1.9680 to 1.9685]
Unit: mm [in.]
Item
Nominal
value
Standard value
Limit
value
Remarks
