Mitsubishi S6R Series User Manual

2-16
Chapter 2 SERVICE DATA
Alternator
P/N:04343-35500
04343-35600
Initial
exciting
type
(brush-
less)
Output
current
(at 27 V)
Rota-
tion
speed
(min
-1
)
2500
30 A or more
(when cold)
5000
35 A or more
(when engine is hot)
Regulator adjusting voltage
(Alternator 5000 min
-1
,
load at 5 A or lower)
28.5 ± 0.5 V
Field coil resistance
(20 °C [68 °F])
7.3 to 8.5 Ω
P/N:04343-38000
Self
exciting
type
(with
brush)
Output
current
(at 27 V)
Rota-
tion
speed
(min
-1
)
2500
26 A or more
(when engine is hot)
5000
30 A or more
(when engine is hot)
Regulator adjusting voltage
(Alternator 5000 min
-1
,
load at 5 A or lower)
28.5 ± 0.5 V
33
[1.3]
32.8 to 33.2
[1.291 to 1.307]
32.4 [1.276]
Height of brushes 21.5 8.0 [0.36]
The part shows
a limit line.
Pressure of brush springs
3.7N
{0.38kgf}
[83.78
lbf]
3.1N to 4.3N
{0.32 to 0.44kgf}
[0.70 to 0.97 lbf]
1.8N
{0.18kgf}
[0.40 lbf]
Belt tension (cogged type)
10 to 15
[0.4 to 0.6]
When the
center of the
belt is pushed
with a force of
approx
98 to 147 N
{10 to 15 kgf}
[22 to 33 lbf]
Alternator P/N:04343-38300
External
exciting
type
(with
brush)
Output
current
(at 27 V)
Rota-
tion
speed
(min
-1
)
2500
29 A or more
(when engine is hot)
5000
35 A or more
(when engine is hot)
Regulator adjusting voltage
(Alternator 5000 min
-1
,
load at 5 A or lower)
28.5 ± 0.5 V
Rotor slip ring
outside diameter
33 [1.3]
32.8 to 33.2
[1.291 to 1.307]
32.4 [1.276]
Height of brushes
21.5
[0.847]
8.0 [0.36]
The part shows
a limit line.
3.7N
{0.38kgf}
[83.78
lbf]
3.1N to 4.3N
{0.32 to 0.44kgf}
[0.70 to 0.97 lbf]
1.8N
{0.18kgf}
[0.40 lbf]
Belt tension (ribbed type)
Refer to the
table below
Unit: mm [in.]
Item
Nominal
value
Standard value Limit value Remarks
