6 - 13
No. 99MBC032A
6. INTERFACE UNIT
6.1.9 Details of command descriptions
(1) CL
(a) Format: CL
(b) Description: Functions same as the
C
key on the Display Unit.
This releases the error state, performs single-run measurement, zero-run
measurement, continuous-run measurement, and releases the measurement
result display latch.
(c) Example: Reception command CL
Transmission command OK
(2) MM, E
(a) Format: MM
E
(b) Description: MM: Sets the display unit to mm.
E: Sets the display unit to E (inch).
(c) Example: Reception command MM or E
Transmission command OK
(3) P
(a) Format: Pp (p: program number)
(b) Description: Program number is changed to the specified one.
(c) Example: Reception command P5
Transmission command OK
(4) HC, LC
(a) Format: HC+ddd.dddd
LC+ddd.dddd
(b) Description: Calibrates the LSM.
If the supplied gage is set in position and this command is executed, the
proportion of the actually measured gage dimension to the entered value is
calculated and the resultant constant is stored in memory, then the “OK”
response will be issued. It requires approximately a second.
(c) Example: Reception command HC24.0005 Transmission command OK
Reception command LC 0.9995 Transmission command OK
(d) Supplement: Negative setup data results in ER2
