LSM-9506

Laser Scan

Micrometer

User's Manual

No.99MBC032A3

SERIES No.544

Read this User’s Manual thoroughly

before operating the instrument. After reading,

retain it close at hand for future reference.

Main Page

Notes for Exporting4
Precautions5
Safety Precaution Labels Located on Lsm-95066
Installing Conditions7
Warranty7
Table of Contents8
Introduction12
Outline12
Foreword12
Nomenclature13
Display Unit13
Measuring Unit14
Setup16
Unpacking and Acceptance Check16
Connecting the Cables16
Preliminary Checks18
Initializing the LSM-950620
Displays and Key Operations22
Outline of the Operation Modes22
Overview22
Setting the Segment24
Measurement Interval (Measurement Time)25
Outline of the Operation Modes26
Basic Setup Mode27
Calibration Mode27
Measuring Condition Setup Mode27
Other Setup Mode27
Statistic Display Mode27
Measurement Mode28
Techniques and Terminology of Setup Functions30
Program30
Basic Setup30
Function Setup31
Setups According to the Property of each Workpiece31
Transparent Object (Workpiece that Transmits Light)31
Latch (Holding) of the Displayed Value33
Automatic Measurement with an Edge Specification34
GO/NG Judgment35
Abnormal Data Elimination37
Offset/Zero-Set38
Mastering38
Reference Value39
Data Output Conditions39
Automatic Workpiece Detection <OD Detection Method, Position Detection Method40
Group Judgment42
Recording the Amount of Light43
Outline of the Display Contents44
Display Unit44
Data Display Unit44
Outline of Key Operations46
Description of Key Functions48
Example Key Operations52
Setting up the Measuring Conditions56
Basic Setup56
Outline of the Basic Setup Procedure57
Description of each Mode58
Selecting and Setting the Function in the B0 Mode59
Setting the Resolution (Guidance: RES)59
Setting the Number of Blank-Out Digits (Guidance: BLN)59
Putting a Comma after the Thousandths Digit (Guidance: )60
Setting the Buzzer Function (Guidance: BUZZER)60
Setting the Display Latch Timer (Guidance: LATCH)61
Selecting and Setting the Function in the B1 Mode62
Setting the Output Function in the Ready State (Guidance: D.OUT)62
Selecting the Display Message if Err-0 Occurs (Guidance: ERR-0 D)62
Selecting the Display Message at the Start of Measurement (Guidance: RUN D)62
Selecting the Averaging Method (Guidance: AVG.M)63
Setting the GO/NG Judgment Method (Guidance: JDG.M)63
Setting Whether the Target Value Is Copied to the Reference Value (Guidance: COPY)63
Selecting and Setting the Function in the B2 Mode64
Setting the Workpiece Type (Guidance: WORK.P)64
Setting the Simultaneous Measurement (Guidance: PROG)64
Selecting the Method of Specifying Segments (Guidance: SEG)64
Selecting and Setting the Function in the B3 Mode65
Setting the Abnormal Value Elimination Function (Guidance: ADE)65
Setting the Automatic Workpiece Detecting Function (Guidance: AWDT)65
Setting the Number of Scans (Guidance: SCAN)65
Setting the Group Judgment (Guidance: GTJ)66
Setting the Group Judgement Output (Guidance: GTJ D)66
Selecting and Setting the Function in the B4 Mode67
Setting the Use of RS-232C Port (Guidance: RS-232C)67
Setting the RS-232C Communication Baud Rate (Guidance: BAUD)67
Setting the RS-232C Communication Data Bits (Guidance: LENGTH)67
Setting the RS-232C Communication Parity Bit (Guidance: PARITY)68
Setting the Delimiter for Communication (Guidance: DELIMT)68
Setting the RS-232C Line Control (Guidance: CONTRL)68
B5: Reserved69
Selecting and Setting the Function in the B6 Mode69
Setting the Use of DCU (Guidance: DCU)69
Calibration70
Calibration Gages and Gage Stand70
Entering the Calibration Mode70
Positioning a Gage or a Workpiece74
How to Read-In the Amount of Light74
Setting up the Functions75
Outline of the Function Setup Mode75
Outline of each Function Setup Mode77
Function Setup Mode78
F0: Setting the Segment78
F1: Setting the Measurement Interval (Measurement Time)80
F2: Setting the GO/NG Judgment Criteria82
F3: Setting the Reference Value86
F4: Setting the Offset Value87
F5: Setting the Data Output Conditions89
F6: Setting the Sample Measurement90
F7: Automatic Workpiece Detection Setting91
F8: Setting the Group Judgment92
Confirming the Function Setup Contents93
Measurement Mode94
Outline of the Measurement Mode94
Setup in the Measurement Mode94
Setup Operation from the Arrow Key95
Setup that Can be Made Directly from each Setup Item Key97
Other Functions98
Key Lock98
Displaying the Measuring Position98
Applied Measurement99
OD Measurement of a Precision-Machined Workpiece99
Measurement of Magnet Coil Wire that Runs at High Speed100
Measurement of the Lead Pitch of a Multiple-Pin IC101
Applied Measurement with Offset/Zero-Set Functions103
Sample Measurement106
Applied Measurement with Automatic Workpiece Detection108
Applied Measurement on a Stepped Round Bar110
Interface Unit112
RS-232C Interface112
Specifications112
Connections114
Printer Interface116
Setting the Printer116
Setting the LSM-9506117
RS-232C Commands117
List of Commands119
List of Response Commands if an Error Occurs121
Format of Response Commands122
Other Commands123
Details of Command Descriptions124
An Example Program of RS-232C Communication132
Digimatic Output Unit Interface133
Method of Use133
I/O Specifications134
Timing Chart135
Data Format136
Inspection and Maintenance138
Display Unit138
Display Check138
Cleaning Method138
Measuring Unit139
Cleaning Optical Parts139
Checking Method of the Reception Signal Using an Oscilloscope139
Replacement of Protection Glass139
Error Messages and Remedies140
Troubleshooting and Remedies141
Fuse Replacement142
Specifications144
Specifications145
Restrictions Associated with the Combination of Functions, Tables of the Basic Setup Modes148
Restrictions Associated with the Particular Combination of Functions148
List of Setup Modes150
List of Basic Setup Modes150
List of Calibration Functions151
Reading in the Amount of Light151
List of Function Setup Modes152
Service Network154
