Description of the unit
22 Operating instructions
3.5.1 Touchscreen operation
The touchscreen can be operated with latex gloves.
Tapping on the touchscreen executes commands that operate the
unit.
Action Function
Tap To select or activate display elements such as
buttons, fields, tabs.
Tap twice To execute special functions by tapping a button
twice rapidly
Wiping gesture To change the page or the set value by moving
up, down, to the left or to the right with the fin-
gertip after first tapping and then maintaining
contact with the field to be changed.
3.5.2 Display elements
The following table lists the basic display elements of the unit's
control system with examples.
Symbol Display element Function
Information bar The information bar is the uppermost bar on the
touchscreen and visible at all times.
The information bar is used to display current in-
formation, for instance, categories or cooking pro-
grams.
Menu Menus have a coloured border that identifies the
associated subject.
•
Blue for equipment functions
and
•
Violet for cooking functions.
Menus frequently contain vertical separating bars
to simplify wiping gestures.
Menus represent central entry points and provide
an overview of the selectable functions and sub-
menus.
Page Pages are the areas with content in windows and
menus. Several pages can follow one another in
sequence.
An arrow symbol displays further pages. Changing
to the next or the previous page is accomplished
by wiping up or down.
10015160-0ABBE--
