Chapter Two: Installation
How To Unpack the Type 248 Unit
MKS has carefully packed the Type 248 unit so that it will reach you in perfect operating order.
Upon receiving the unit, however, you should check for defects, cracks, broken connectors, etc.,
to be certain that damage has not occurred during shipment.
Note
Do not discard any packing materials until you have completed your
inspection and are sure the unit arrived safely.
If you find any damage, notify your carrier and MKS immediately. If it is necessary to return the
unit to MKS, obtain an RMA Number (Return Material Authorization Number) from the MKS
Service Center before shipping. Please refer to the inside of the back cover of this manual for a
list of MKS Calibration and Service Centers.
Unpacking Checklist
Standard Equipment:
• Type 248 Unit
• Type 248 Instruction Manual (this book)
Optional Equipment:
• Electrical Connector Accessories Kit - 248A-K1
• Interface cables:
CB251-2-10 Connects the 248 valve to a Type 250D-E or 1250 controller
CB251-1-10 Connects the 248 valve to a Type 250A-C, or 260 controller
Note
1. Overall metal, braided shielded cables are required to meet CE Mark
specifications.
2. To order a metal braided, shielded cable, add an “S” after the cable
type designation. For example, to order a standard cable to connect
the 248 valve to a 250D-E controller, use part number CB251-2-10;
for a metal, braided, shielded cable use part number CB251S-2-10
