Setup Cha
p
ter Two: Installation
28
1.45 (36.8)
Figure 2: Side View of the Type 1179 MFC and Type 179 MFM
0.625
(15.8)
0.125 (3.1)
3.38
(85.9)
5.43 (137.9) with
Type "D" connector
5.30 (134.6) with
PC Ed
g
e Board
Connector
or
Figure 3: Outline Dimensions of the Type 2179 MFC (with optional mounting plate)
