8-504.11
IMPORTANT
1. Refrigerant charging should only be carried out
by an EPA-certied air conditioning contractor.
2. This appliance is not intended to be operated
or serviced by persons (including children) with
reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless
they have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety.
3. Children should be supervised to ensure that
they do not play with the appliance.
IMPORTANT
1. L’ajout de frigorigène doit être coné à un
spécialiste de la climatisation certié par
l’agence de la protection de l’environnement
(EPA) du gouvernement américain.
2. Cet appareil n’est pas conçu pour être utilisé
ou entretenu par des personnes (y compris
des enfants) dont les capacités physiques,
sensorielles ou mentales sont réduites, ou qui
n’ont pas l’expérience et les connaissances
su󰀩santes, à moins d’être supervisées ou
d’avoir obtenu des directives concernant
l’utilisation de l’appareil par une personne
responsable de leur sécurité.
3. Les enfants doivent être supervisés pour
s’assurer qu’ils ne jouent pas avec l’appareil.
INSPECTION ON ARRIVAL
1. Inspect unit upon arrival. In case of damage, report
immediately to transportation company and your local factory
sales representative.
2. Check serial plate on unit to verify that the power supply
meets available electric power at the point of installation.
3. Inspect unit upon arrival for conformance with description of
product ordered (including specications where applicable)
TABLE OF CONTENTS
Special Precautions .............................................................3
Hazard Intensity Levels ........................................................3
Special Design Requests .....................................................5
Unit Location ........................................................................6
Unpacking ..........................................................................6
Blank O󰀨 Pieces ................................................................6
Preparation ........................................................................6
Ceiling Opening Sizes ........................................................6
Positioning Wall Mounted Thermostat ...............................7
Installation ............................................................................8
Hanger Bolts ......................................................................8
Installation Guide ...............................................................8
Condensate Piping .............................................................9
Duct Collars .......................................................................9
Piping Installation .............................................................10
Wiring ............................................................................... 11
Disconnect Switch ............................................................12
Terminal Strip Connections ..............................................12
Remote Condensing Unit Terminal Strip Connections .....12
Fascia Assembly ..............................................................12
Start-Up Procedure ............................................................13
Start Up Sheet - Example ..................................................14
Sequence of Operation ......................................................16
Micro-Processor Operation ................................................18
Dimensions ........................................................................20
Small Chassis: Chilled Water Units .................................20
Medium Chassis: Chilled Water Units ..............................21
Large Chassis: Chilled Water Units .................................22
Medium Chassis: DX and Heat Pump units .....................23
Large Chassis: DX and Heat Pump units ........................24
DX Cooling Only and Heat Pump Units - IP Units ...........26
DX Cooling Only and Heat Pump Units - SI Units ...........27
Chilled Water Units - IP Units ...........................................28
Chilled Water Units - SI Units ..........................................29
Exploded Unit Drawing & Parts List – Chilled Water .........30
Exploded Unit Drawing & Parts List – DX & Heat Pump ....31
Maintenance ......................................................................32
Disassembly Procedure ...................................................33
Replacement Parts ..........................................................33
Model Identication ............................................................34
Troubleshooting .................................................................35
