TECHNICAL DATA
DX Cooling Only and Heat Pump Units - SI Units
Table 27.1 - Technical Data - DX Cooling Only and Heat Pump Units - SI Units
Model Digit 2,3 + Model Size
DESCRIPTION UNITS SD/SH 18 SD/SH 24 SD/SH 30 SD/SH 36 SD/SH 42
CAPACITY
Total Cooling Capacity (1) kW 5.6 6.7 9.2 11.2 12.5
Sensible Cooling Capacity (1) kW 4.6 5.3 7.9 8.9 9.8
Nominal Heating Capacity (2) kW 4.8 6.3 8.0 9.5 10.9
CONSTRUCTION
Material: Fascia
High Impact Polystyrene (Light Grey color), UL 94 VO Fire Rating
Material: Chassis Galvanized Steel
EVAPORATOR
Type Finned Tube
Quantity 1
Face Area m² 0.37 0.48
Nominal Airow - H/M/L m³/min 16.7 / 15.3 / 13.2 19.0 / 16.7 / 15.3 26.1 / 22.7 / 19.3 28.3 / 26.1 / 22.7 32.0 / 28.3 / 26.1
Discharge 4-Way
FAN
Type Centrifugal
Quantity 1 2
Diameter cm 35.6
Horsepower (per fan) Watts 124
REFRIGERATION
Number of Circuits 1
Refrigerant Type R-410A
WEIGHTS
Weight - Chassis
kg
29.9 44.0
Weight - Fascia 8.2 9.5
CONNECTIONS
Suction (3)
cm
1.9
Liquid (3) 0.95
Condensate (ID) 0.93
FILTRATION
Type Washable Polyester Foam (Standard)
Size (5) cm 29.5 x 58.9 x 0.5
Type MERV 10
Nominal Size (5) cm 30.5 x 63.5 x 2.5
Quantity 2 3
CONDENSATE PUMP
Maximum Head cm 76.2
Nominal Flow-rate l/m 0.38
OPTIONS
Electric Heating Capacity kW 3.0 5.0
HW Heating Capacity (4) kW 11.4 12.3 16.6 17.5 18.8
HW Coil Connection (OD) cm 2.2
Max Supply Air Branch Duct
Connections
qty 2
Supply Air Branch Duct
Diameter
cm 12.7 15.2
Ducted Supply Air Volume (5) m³/min 3.3 3.7 5.1 5.7 6.2
Fresh Air Connections qty 3
Fresh Air Duct Diameter cm 7.6
Fresh Air Volume (6) m³/min 1.7 1.8 2.4 2.5 2.7
(1) Nominal cooling capacity based on 80/67°F (26.7/19.4°C) DB/WB and 95/75ºF (35/23.9°C) DB/WB ambient and High Speed.
(2) Nominal heating capacity based on 70/60°F (21.1/15.6°C) DB/WB and 47/43°F (8.3/6.1°C) DB/WB ambient and High Speed for Heat Pump models (Digit 3 = H)
(3) Refrigerant line sizes should always match condensing unit connection sizes.
(4) Nominal heating capacity based on 70/60°F (21.1/15.6°C) DB/WB and water temperature of 180ºF (82.2°C) inlet / 160ºF (71.1°C) outlet.
(5) Maximum air volume available through one branch duct 6 ft (1.8 m) long, with Cassette fan(s) at high speed and corresponding fascia aperture closed.
(6) Maximum fresh air through all knockouts connected to one 10 ft (3.1 m) long duct with fan at high speed. Fresh air volume will depend on duct configuration, fan speed,
and filter type.
(7) For conditions different to those shown, refer to Accuspec Breeze.
