-29-
Revision 2/F3509
Two Screws
6.3.18 OUTER GLASS
6.3.17 MOTOR
1) Remove fan (refer 6.2.16) and then
remove the wires that go to the motor.
1) Open door
2) Loosen the two screws securing the top
pivot whilst supporting the door. The pivot
can now be lifted, and the door removed
from the oven.
Figure 6.3.22
2) Unscrew the elements from inside the
oven.
3) Pull elements carefully to remove. Sili-
cone sealant may require effort to remove
elements.
4) Replace and re-assemble in reverse
order. Use high temperature (232°C /
450°F minimum) RTV silicone sealant to
seal element against side wall of oven.
Element Rating:
208-220 V Inner Element 17.0 ohms
Outer Element 14.1 ohms
230-240 V Inner Element 19.4 ohms
Outer Element 17.0 ohms
2) Undo the three screws holding the motor
in place (from the outside) and remove
motor.
3) Remove screws securing door handle,
and remove handle from the door assem-
bly.
Figure 6.3.21
Element Screw
Element
Wires
6.3.16 FAN
1) With baffle removed undo the centre nut.
NOTE: LH thread - Turn clockwise to
loosen.
Figure 6.3.25
Screws (3)
3) Replace and re-assemble in reverse
order.
4) Ensure wire connections are correct to the
voltage supply—60 Hz / 50 Hz (fig 6.3.24)
60 Hz
Terminal
50 Hz
Terminal
Earth /
Ground
Neutral
2) Replace and re-assemble in reverse
order.
Figure 6.3.24
Centre Nut
Figure 6.3.23
To Next Page
