Moffat Turbofan E32 - Inner Glass

-30-
Revision 2/F3509
Door Seals
Four Screws
Four
Screws
6.3.19 INNER GLASS
1) Remove the outer glass (refer 6.3.18).
Uncrimp the retaining lugs of the window
spacer and remove the spacer and glass.
2) To replace, ensure the silicone rubber
seal has not been displaced. Clean the
glass and refit it. Place the window
spacer in position and crimp the retaining
lugs over to hold the glass in place. Refit
outer glass as above.
Retaining
Lugs
Figure 6.3.26
4) Remove four screws in top trim and four
screws in bottom trim of door, and remove
trim panels.
Figure 6.3.28
Figure 6.3.27
5) Lift outer glass away from door.
6) To replace, ensure that the two silicone
rubber seals are in place on the left hand
and right hand side of the door frame.
Clean the inside of the glass and refit it,
ensuring that the silicone rubber seals
cover the outer edges of the glass. Refit
the trim panels.
Screws
Figure 6.3.29
Figure 6.3.30
6.3.20 DOOR SEALS
1) Open oven door.
2) To remove, hold at their centre point and
pull forward until they unclip
3) Refit new seals.
Note: Fit top and bottom seals first, with
open side of seal facing down-
wards. Fit side seals with open
side facing outwards.
6.3.21 DOOR PIVOT BUSHES
1) Remove door as per steps one and two of
section 6.3.18.
2) Remove the top and bottom pivot brackets
(two screws).
Two Screws
