6.4.3 DOOR CATCH ADJUSTMENT
6.4.2 DOOR MICROSWITCH ADJUSTMENT
1) Open oven door.
2) Open control panel (refer 6.2.1).
3) With fingers, bend actuator arm of
microswitch so that switch operates when
door is in closed position.
1) Open the control panel (refer 6.2.1).
2) Loosen the four screws securing the
chrome plated bar which carries the door
catches.
3) The door catches can now be adjusted in
or out to ensure that the door seals cor-
rectly.
4) Tighten the screws and close the control
panel.
Actuator Arm
Figure 6.4.6
Figure 6.4.9
Figure 6.4.7
6.4.5 HOLD TEMPERATURE ADJUSTMENT
1) The hold temperature of the oven can be
adjusted by turning the hold thermostat
dial to the desired hold temperature. This
dial is located inside the control panel.
Hold Thermostat
Dial
Figure 6.4.10
6.4.6 60 MINUTE TIMER ZERO POSITION
ADJUSTMENT
1) Remove 60 minute timer knob by pulling it
firmly away from control panel.
2) Open control panel (refer 6.2.1). Loosen
two screws on control panel holding 60
minute timer.
Two Screws
3) The timer can now be rotated as required
to ensure that the buzzer sounds at the
zero position.
Four Screws
6.4.4 DOOR ALIGNMENT
1) Loosen the three screws securing the bot-
tom hinge to the oven front.
Figure 6.4.8
2) Adjust hinge position to align door latch
with catch plate on side of door.
Three screws
