Moog curlin 6000 series Clinician Instructions

LCD DISPLAY/RESOLUTION/POSSIBLE CAUSES
INFUSION
COMPLETE
AIR-IN-LINE
ALARM DOWN
OCCLUSION
ALARM UP
OCCLUSION
ALARM HIGH UP
PRESSURE
ALARM SET NOT
INSTALLED
ALARM
UNATTENDED
ALARM REPLACE
SET 3
ALARM REPLACE
SET 4
ALARM DOOR
OPEN
ALARM EMPTY
BATTERY
ERROR CODE
Press PAUSE, attach new solution container, highlight REPEAT RX and press YES.
The program will auto-scroll (or conrm each eld by pressing YES). If therapy is
complete, turn pump o.
Press the PRIME key, then follow on-screen instructions to remove air from the
tubing and IV bag. CAUTION: Disconnect set from patient’s access site before
priming. Sets with in-line ASVs must be primed on the pump.
Down occlusions auto-correct when occlusion is resolved without the need to press
PAUSE. Check the tubing from pump to patient’s IV site for cause, then correct
obstruction per protocol. Consider changing the DN Occlu setting from LOW to
HIGH (See OPTIONS section). Possible causes: kinked or clamped line, inltrated/
positional IV site, viscous solution, small gauge catheter.
Check tubing from pump to IV bag for cause, then correct obstruction per protocol.
Possible causes: glass container without vented spike adapter, line kinked in pump
door, bag empty, bag not spiked properly.
Check for excessive pressure on IV bag. Causes: uneven uid distribution within
lockbox or carrying pouch, object pressing on solution container.
Use only Curlin administration sets. Check that set is installed properly. Refer to
Instructions for Use in set package or Installing Administration Set section in this
guide. Possible causes: tab not removed from yellow Flow-Stop, blue guide pin or
yellow ow-stop not properly seated in receptacles, no set installed.
The pump will alarm when left idle for 2 minutes. Press RUN to start the infusion or
press OFF to power down the pump.
Replace set and prime if necessary. Possible causes: attening of the soft pumping
segment of the set due to overuse, use of a glass container without a vented spike
adapter, excessive plunger stiction with syringe use.
Equalize the pressure in the set by priming (disconnect from the patient). Turn
pump OFF then ON to reset the sensor prior to resuming the infusion.
Check placement of the administration set and close pump door properly. See
User’s Manual for instructions.
Turn pump o by pressing the OFF key. Install 2 new batteries and turn pump back
on.
If an error code occurs, turn pump o and consult provider or manufacturer.
TROUBLESHOOTING:
NOTE: For all alarms except “INFUSION COMPLETE”, follow these instructions before proceeding to the
RESOLUTION section below: To silence and exit Alarm/Alert screens, press the PAUSE key, press YES to
RESUME, then resolve the alarm. When ready to resume the infusion, press RUN to start the infusion.
TROUBLESHOOTING
