Moons' RS03-S-A - Am23 Rs

RS03/06-S/Q Hardware Manual
32
9 / 28 / 2015
+86-400-820-9661
AM23RS
47.14
47.14
φ38.1
4-φ5.1
56.3
A
A1 FLAT
B
B1
1.6L
7
30033
73.6
Type(Unit: mm)
Model A A1 B B1 L
AM23RS2DMA
φ
8 7.5 24 20 77.5
AM23RS2DMB
φ
6.35 5.85 20 15 77.5
AM23RS3DMA
φ
8 7.5 24 20 99.5
AM23RS3DMB
φ
6.35 5.85 20 15 99.5
AM23RS4DMA
φ
8 7.5 24 20 102.5
