5.6 Motor Numbering System
AM17 RS 1 D M A
Frame Size
11,17,23,24
Motor Size
1 = 1Stack
2 = 2Stack
3 = 3Stack
4 = 4Stack
Step Servo
D=DC Input
Mechanical Option
A=Output shaft size
11:φ5
17:φ6
23:φ8
24:φ10
B=Output shaft size
17:φ5
23:φ6.35
24:φ8
Encoder
M=1024-Line
5.7 Drive Numbering System
RS 03 - S - A
Output Current
03 - 3A
06 - 6A
Step Servo
S = Basic Type
Q = Q Type
A = RS-232
