11
Rev. 0.1
8/30/2019
SRX04 Hardware Manual
Inputs connection examples
Controller
SRX04 Drive
STEP+
Pulse signal
Direction
signal
Enable signal
STEP-
DIR+
DIR-
EN+
EN-
VCC
Common anode
STEP+
STEP-
DIR+
DIR-
EN+
EN-
VCC
VCC
VCC
GND
Common cathode
Controller
SRX04 Drive
Pulse signal
Direction
signal
Enable
signal
STEP+
STEP-
DIR+
DIR-
EN+
EN-
STEP+
STEP-
DIR+
DIR-
EN+
EN-
Differential
Controller
SRX04 Drive
Pulse signal
Direction signal
Enable signal
