SRX04 Hardware Manual
4 Mounting the Drive
The SRX4 Step Drive can be mounted on the wide or the narrow side of the chassis. If it is mount-
ed on the wide side, M3 screws should be used through the four corner holes. For narrow side
mounting applications, M3 screws can be used in the two side holes.
The amplifiers in the drive generate heat. To operate the drive continuously at maximum power
forced air cooling, as from a fan, should be provided.
Never use the drive in a space where there is no air flow or where other devices can cause the
surrounding air to be more than 40 °C. Never put the drive where it can get wet or where metal
particles can fall into it.
