6.3 Recommended Motor
■ Standard type step motor
Model Features
Lead
number
Length
Holding
Torque
Drive Current
Setting Range
※
Rotor
Inertia
Mass
Mass
Dielectric
Strength
mm N.m A g.cm
2
Kg
AM8HY2050-01N Single Shaft 4
29.5 0.02
0.1~0.5
1.6 0.04
500VAC/
1Minute
AM8HY2050-02N Double Shaft 4
AM8HY4043-01N Single Shaft 4
46.5 0.042 4.2 0.09
AM8HY4043-02N Double Shaft 4
AM11HS1008-07 Single Shaft 4 31 0.072
0.1~1.6
9 0.1
AM11HS3007-02 Single Shaft 4 40 0.082 12 0.15
AM11HS5008-01 Single Shaft 4 51 0.125 18 0.2
AM14HS10A0-01 Single Shaft 4
27.3 0.14
0.1~1.0
12 0.15
AM14HS10A0-02 Double Shaft 4
AM14HS30A0-01 Single Shaft 4
36 0.23 20 0.21
AM14HS30A0-02 Double Shaft 4
AM14HS50A0-01 Single Shaft 4
55.5 0.4 35 0.24
AM14HS50A0-02 Double Shaft 4
AM17HD4452-02N Single Shaft 4
34.3 0.285 0.1~1.8 38 0.23
AM17HD4452-01N Double Shaft 4
AM17HD2438-02N Single Shaft 4
39.8 0.46 0.1~1.8 57 0.28
AM17HD2438-01N Double Shaft 4
AM17HD6426-06N Single Shaft 4
48.3 0.59 0.1~1.8 82 0.36
AM17HD6426-05N Double Shaft 4
AM17HDB410-01N Single Shaft 4
62.8 0.85 0.1~1.6 123 0.6
AM17HDB410-02N Double Shaft 4
AM23HS0420-01 Single Shaft
4 41 0.72 0.1~2.2 135 0.42
AM23HS0420-02 Double Shaft
AM23HS2449-01 Single Shaft 4
54 1.25 0.1~2.2 260 0.6
AM23HS2449-02 Double Shaft 4
AM23HS3454-01 Single Shaft 4
76 2.1 0.1~2.2 460 1
AM23HS3454-02 Double Shaft 4
AM23HS0421-01 Single Shaft 4
41 0.72 0.1~4.5 135 0.42
AM23HS0421-02 Double Shaft 4
AM23HS2450-01 Single Shaft 4
54 1.25 0.1~4.5 260 0.6
AM23HS2450-02 Double Shaft 4
AM23HS3455-01 Single Shaft 4
76 2.1 0.1~4.5 460 1
AM23HS3455-02 Double Shaft 4
AM23HS04A0-01 Single Shaft 4
39 0.82 0.1~2.2 105 0.4
AM23HS04A0-02 Double Shaft 4
AM23HS84A0-01 Single Shaft 4
55 1.5 0.1~2.2 215 0.6
AM23HS84A0-02 Double Shaft 4
AM23HSA4A0-01 Single Shaft 4
77 2.3 0.1~2.2 365 1
AM23HSA4A0-02 Double Shaft 4
AM23HS04B0-01 Single Shaft 4
39 0.82 0.1~4.5 105 0.4
AM23HS04B0-02 Double Shaft 4
AM23HS84B0-01 Single Shaft 4
55 1.5 0.1~4.5 215 0.6
AM23HS84B0-02 Double Shaft 4
AM23HSA4B0-01 Single Shaft 4
77 2.3 0.1~4.5 365 1
AM23HSA4B0-02 Double Shaft 4
AM23HS04B0-03 Single Shaft 4
39 0.82 0.1~4.5 105 0.4
AM23HS04B0-04 Double Shaft 4
AM23HS84B0-03 Single Shaft 4
55 1.5 0.1~4.5 215 0.6
AM23HS84B0-04 Double Shaft 4
AM23HSA4B0-03 Single Shaft 4
77 2.3 0.1~4.5 365 1
AM23HSA4B0-04 Double Shaft 4
AM24HS2402-08N Single Shaft 4
54 1.57 0.1~4.5 450 0.83
AM24HS2402-11N Double Shaft 4
AM24HS5401-10N Single Shaft 4
85 3.2 0.1~4.5 900 1.4
AM24HS5401-24N Double Shaft 4
AM34HD0404-08 Single Shaft 4
66.5 3.7 0.1~7.0 1100 1.6
AM34HD0404-09 Double Shaft 4
AM34HD1404-06 Single Shaft 4
96 6.7 0.1~7.0 1850 2.7
AM34HD1404-07 Double Shaft 4
AM34HD2403-07 Single Shaft 4
125.5 9.4 0.1~7.0 2750 3.8
AM34HD2403-08 Double Shaft 4
AM34HD3402-01 Single Shaft 4
156 11.5 0.1~7.0 4400 5.2
AM34HD3402-02 Double Shaft 4
※
The current value of the driver is the sinusoidal peak.
