Morgana AutoFold Pro - Fold Settings

Page 17
SYSTEM
Fold Settings Pages.
To get to the Fold setting page click the lower tab or from the
status area.
If you have selected a predefined standard Fold Type from the paper settings page the
recommended crease positions can be viewed by selecting the crease position button.
Folds in ‘Set By Fold’ mode.
AutoFold Pro
Operating the AutoFold Pro
Folding on/off selector
green is on & red is off.
This is also indicated in
the status area.
With Folding turned off the
deflect positioned can be
micro adjusted.
Micro adjust range is -5.0
to +5.0 with increments of
0.1mm
Folding can be Micro
adjusted for fine
Micro adjust range is -5.0
to +5.0 with increments
of 0.1mm
adjustment.
K1 Fold micro adjust - On
selection the status area is
replaced with a calculator
for inputting new values.
Micro adjust range is -5.0
to +5.0 with increments of
0.1mm
Crease Position
Button
