Morgana AutoFold Pro - Folds in Set by Position- Mode

Page 18
FOLDING
Folds in ‘Set By Position’ mode.
Operating the AutoFold Pro
Fold distance from lead
edge for knives (K1 & K2)
increments of 0.1mm
Clicking this icon switches
deflect off &K1 returns to
its original position.
K1 deflect button
K1 micro adjust selected
K1 in deflect position.
This can be micro adjusted.
Micro adjust range is -5.0
to +5.0 with increments of
0.1mm
K1 & K2 in deflect position.
This can be micro adjusted.
Micro adjust range is -5.0
to +5.0 with increments of
0.1mm
