October 12, 2005 HLN6923A
2-12 Standard Configurations: Radio Mounting
Figure 2-18. Control Head Installation Exploded View
Figure 2-19. Control Head Rear View
IMPORTANT
USE A METAL BACKING PLATE
(NOT SUPPLIED) IF MOUNTING
TRUNNION ON A PLASTIC DASHBOARD
DRILL FOUR 5/32"
HOLES IN DASHBOARD
DASHBOARD
TRUNNION
USE FOUR MOUNTING SCREWS
ON ALL INSTALLATIONS
ADJUST THE CONTROL HEAD
TO DESIRED ANGLE AND
SECURE WITH WING SCREWS
