Mounting Adapter View, Surface Mount

Lanyard

Connects to the lanyard anchor on the camera base.

Camera housing clips

Snaps to hold camera module during installation.

Cable entry hole

An entry hole for the cables required for camera operation.

Mounting holes

Holes for mounting the adapter to the following:

A — UK standard single gang box

B — Octagon gang box

D — US standard single gang box

Mounting Adapter View, Surface Mount 5
