Removing the Dome Cover
Note: Be careful not to scratch or touch the dome bubble. The resulting marks or fingerprints may
affect the overall image quality. Keep the protective covers on the outside of the dome bubble
until the installation is complete.
l Remove the dome cover by releasing the elastic strap holding the dome cover to the camera base.
Inserting Cables through the Sealing Grommet
Always use the provided sealing grommet to prevent dust and debris from entering the camera.
1. Remove the sealing grommet from the camera base.
2. Push the Ethernet cable through the grommet.
If you are installing the indoor model (H5SL-D), you should be able to simply push the cable, crimped
or uncrimped, through the grommet by hand.
If you are installing the outdoor model (H5SL-DO), use one of the following methods:
Removing the Dome Cover 13
