Section 4: 4-10 VHF (136–174 MHz) 1–25 W LDMOS PCB 8471235L04, Schematics, and Parts Lists
6881091C63-F
FL3114 9180468V06 SMD455KHZ 4 ELEMENT CER
FLTR
J3401 0986166B01 MOBILE RF CONNECTOR
(BNC)
L3002 2414032D23 470nH
L3031 2414032D24 560nH
L3032 2414032D17 150nH
L3101 2414032D25 620nH
L3111 2414032D25 620nH
L3112 2414032D25 620nH
L3124 2414032B68 1uH
L3201 2414017Q42 390nH
L3231 2414017Q20 2.2uH
L3301 2414032B44 18nH
L3302 2414032B53 100nH
L3317 2414032F28 33nH
L3318 2414032F34 100nH
L3331 2414032F32 68nH
L3332 2414032F15 100nH
L3333 2414017Q47 1uH
L3341 2415385H01 8nH
L3343 2414032B56 180nH
L3344 2414032B68 1uH
L3345 2414032B68 1uH
L3346 2415385H07 35.5nH
L3351 2414032B68 1uH
L3361 2414032B50 56nH
L3362 2414032B51 68nH
L3363 2414032B50 56nH
L3364 2414032B68 1uH
L3401 2460591A01 4.22nH
L3402 2415954H02 INDUCTOR BEAD
L3403 2414032D13 68nH
L3411 2414032D13 68nH
L3412 2414032B42 12nH
L3414 2460591A11 7.66nH
L3421 2415954H02 INDUCTOR BEAD
L3422 2460591C23 13.85
L3436 2415954H02 INDUCTOR BEAD
L3437 2460592A01 17nH
L3443 2460591X02 INDUCTOR BEAD
L3471 2414032B69 1.2uH
L3472 2460592B01 51nH
L3491 2460592B01 51nH
L3492 2460592B01 51nH
L3493 2460592B01 51nH
M3421 2686201B02 HEATSPREADER
Q3001 4802197J95 RF TRANSISTOR PBR941
Q3002 4813973A13 PNP
Q3021 4816097H01 XISTOR FMC2 RH
Q3101 4802197J95 RF TRANSISTOR PBR941
Q3102 4802197J95 RF TRANSISTOR PBR941
Q3141 4813973M07 PNP
Q3151 4813973A42 PNP
Q3152 4813973A42 PNP
Q3221 4813973A42 PNP
Circuit
Ref
Motorola
Part No.
Description
Q3301 4802197J95 RF TRANSISTOR PBR941
Q3303 4815055H01 TSTR DUAL NPN/PNP
Q3304 4805218N63 RF TRANS SOT 323 BFQ67W
Q3411 4816097H01 XISTOR FMC2 RH
Q3421 4813976A04 TRANSISTOR MRF1518
Q3422 4813973A42 PNP
Q3441 4816121H01 LD MOS PWR MRF1565
Q3442 4813973A42 PNP
Q3471 4813973A42 PNP
Q3472 4816049H01 MEDIUM PWR TRANSISTOR
Q4451 4813973M07 PNP
R3000 0613952H77 1500 Ohm
R3001 0613952J25 100K Ohm
R3002 0613952H67 560 Ohm
R3003 0613952H73 1000 Ohm
R3004 0613952H77 1500 Ohm
R3006 0613952J01 10K Ohm
R3009 0613952J25 100K Ohm
R3010 0613952H69 680 Ohm
R3011 0613952H89 4700 Ohm
R3012 0613952H73 1000 Ohm
R3013 0613952H85 3300 Ohm
R3014 0613952H42 51.0 Ohm
R3015 0613952H25 10.0 Ohm
R3016 0613952H25 10.0 Ohm
R3018 0613952H57 220 Ohm
R3019 0613952J17 47K Ohm
R3021 0613952H67 560 Ohm
R3024 0613952H63 390 Ohm
R3025 0613952H77 1500 Ohm
R3026 0613952J01 10K Ohm
R3027 0613952J01 10K Ohm
R3028 0613952H63 390 Ohm
R3031 0613952H42 51.0 Ohm
R3033 0613952G67 0.0 Ohm
R3101 0613952J03 12K Ohm
R3102 0613952H25 10.0 Ohm
R3105 0613952H49 100 Ohm
R3106 0613952J11 27K Ohm
R3107 0613952H82 2400 Ohm
R3108 0613952H75 1200 Ohm
R3111 0613952J03 12K Ohm
R3112 0613952H25 10.0 Ohm
R3113 0613952H61 330 Ohm
R3115 0613952H63 390 Ohm
R3116 0613952H81 2200 Ohm
R3117 0613952J11 27K Ohm
R3118 0613952H82 2400 Ohm
R3124 0613952H73 1000 Ohm
R3130 0613952H42 51.0 Ohm
R3132 0613952J05 15K Ohm
R3133 0613952H89 4700 Ohm
R3134 0613952H95 8200 Ohm
R3135 0613952H75 1200 Ohm
R3141 0613952H63 390 Ohm
R3142 0613952H79 1800 Ohm
Circuit
Ref
Motorola
Part No.
Description
R3144 0613952H82 2400 Ohm
R3145 0613952H85 3300 Ohm
R3146 0613952H69 680 Ohm
R3147 0613952J03 12K Ohm
R3151 0613952J01 10K Ohm
R3152 0613952J01 10K Ohm
R3153 0613952J01 10K Ohm
R3154 0613952J01 10K Ohm
R3201 0613952H41 47.0 Ohm
R3203 0613952H41 47.0 Ohm
R3204 0613952H41 47.0 Ohm
R3211 0613952G67 0.0 Ohm
R3221 0613952H63 390 Ohm
R3222 0613952H69 680 Ohm
R3223 0613952H49 100 Ohm
R3224 0613952J17 47K Ohm
R3225 0613952J17 47K Ohm
R3227 0613952J25 100K Ohm
R3241 0613952H49 100 Ohm
R3242 0613952G67 0.0 Ohm
R3251 0613952J31 180K Ohm
R3252 0613952J37 330K Ohm
R3261 0613952J17 47K Ohm
R3263 0613952H89 4700 Ohm
R3301 0613952H46 75.0 Ohm
R3302 0613952H49 100 Ohm
R3303 0613952H81 2200 Ohm
R3304 0613952H73 1000 Ohm
R3308 0613952G67 0.0 Ohm
R3311 0613952H49 100 Ohm
R3316 0613952G67 0.0 Ohm
R3318 0613952H33 22.0 Ohm
R3321 0613952J01 10K Ohm
R3323 0613952H73 1000 Ohm
R3331 0613952H41 47.0 Ohm
R3335 0613952H37 33.0 Ohm
R3336 0613952J05 15K Ohm
R3341 0613952H57 220 Ohm
R3342 0613952H39 39.0 Ohm
R3343 0613952H49 100 Ohm
R3351 0613952J08 20K Ohm
R3352 0613952J03 12K Ohm
R3353 0613952J25 100K Ohm
R3354 0613952J29 150K Ohm
R3355 0613952J08 20K Ohm
R3356 0613952J03 12K Ohm
R3361 0613952H57 220 Ohm
R3362 0613952H41 47.0 Ohm
R3364 0613952J17 47K Ohm
R3400 0613952H65 470 Ohm
R3401 0613952H60 300 Ohm
R3402 0613952H29 15.0 Ohm
R3403 0613952H60 300 Ohm
R3404 0613952J17 47K Ohm
R3405 0613952H49 100 Ohm
R3406 0613952J25 100K Ohm
Circuit
Ref
Motorola
Part No.
Description
R3407 0613958H18 5.1 Ohm
R3411 0613952H70 750 Ohm
R3412 0613952H73 1000 Ohm
R3413 0613952H85 3300 Ohm
R3414 0613959Y51 120 Ohm
R3415 0613952H38 36.0 Ohm
R3416 0613952H38 36.0 Ohm
R3418 0613952J09 22K Ohm
R3421 0613952J15 39K Ohm
R3422 0613952H81 2200 Ohm
R3423 0613952J15 39K Ohm
R3424 0613958H11 2.7 Ohm
R3425 0613958H11 2.7 Ohm
R3426 0613958H11 2.7 Ohm
R3427 0613958H11 2.7 Ohm
R3428 0613952H82 2400 Ohm
R3429 0613952H57 220 Ohm
R3431 0613959Y42 51 Ohm
R3432 0613959Y42 51 Ohm
R3433 0613958H11 2.7 Ohm
R3434 0613958H11 2.7 Ohm
R3435 0613958H11 2.7 Ohm
R3441 0613952J15 39K Ohm
R3442 0613952H81 2200 Ohm
R3443 0613952J15 39K Ohm
R3444 0613958H17 4.7 Ohm
R3445 0613952H82 2400 Ohm
R3446 0613952G67 0.0 Ohm
R3450 0613952H65 470 Ohm
R3452 0613952J03 12K Ohm
R3454 0613952J12 30K Ohm
R3455 0613952J25 100K Ohm
R3457 0613959Y51 120 Ohm
R3471 0613952H65 470 Ohm
R3473 0613959Y42 51 Ohm
R3474 0613959Y42 51 Ohm
R3475 0613952J01 10K Ohm
R3491 0613952J01 10K Ohm
R3492 2415347H01 1uH
R3501 0613952H93 6800 Ohm
R3502 0613952J15 39K Ohm
R3504 0613952J01 10K Ohm
R3505 0613952J36 300K Ohm
R3507 0613952J08 20K Ohm
R3508 0613952J25 100K Ohm
R3509 0613952H73 1000 Ohm
R3510 0613952J25 100K Ohm
R3511 0613952H81 2200 Ohm
R3513 0613952G67 0.0 Ohm
RT3404 0686462W35 MULTI-LAYER NTC
THERMISTOR 10K
SH3301 2602641Y03 SHIELD ARIANE VCO
T3001 2566506A01 BALUN TRANSFORMER
T3002 2566506A02 BALUN TRANSFORMER
U3101 5115281H01 FM IF IC SA616 FROM PHILIPS
U3111 5185291Y01 QUAD ANALOG SWITCH
Circuit
Ref
Motorola
Part No.
Description
