Section 10: 3-6 Troubleshooting Flow Chart for PassPort

6881091C63-F

5.0 Troubleshooting Flow Chart for PassPort

Troubleshooting in PassPort mode must be completed in conventional mode. If any issues related

to the option board are discovered, the PassPort board should be replaced.

Start

Check Radio Operation on a

Non-PassPort Zone with a

Conventional Personality without

the Option Board Enabled

OK?

Check Radio PassPort

Programming using CPS

Check Switched B+

and Vdd from Radio on PTCB

OK?

Check Radio PassPort

Programming using CPS

Rx Demod

J601-6?

Tx Mod

J601-10?

Install and Reprogram a

new PassPort Trunking

Controller Board

Repair Radio

Yes
