Control Head CDM1250 / PRO5100 / CDM1550 Series / PRO7100 Troubleshooting Flow Charts Section 2: 3-3

6881091C63-F

2.0 Control Head CDM1250 / PRO5100 / CDM1550 Series / PRO7100

Troubleshooting Flow Charts

2.1 Troubleshooting Flow Chart for On/Off

Radio does not turn on when On/Off/Volume Knob is

pressed

YES

R0823 Pin TAB

= 5V?

R0823 Pin TAB1

when pressed

= 5V?

Check / Replace

Volume Pot R0823

Check / Replace

R0822 / VR0822 /

D0822 / C0822

YES

J0801 Pin 2

> 10V?

Check / Replace

Q0821

Check / Replace

Q0822 / R0821

YES

J0801 Pin 2

=5V?

Check / Replace

D0821 / R0852

Press and hold

On/Off/Volume Knob
