Motorola CDM Series User Manual

Low Band Range 3 (42–50 MHz) PCBs, Schematics, and Parts Lists Section 7: 4-97
6881091C63-F
C1144 2113945C31 CAP, .1uF
C1145 2113945L41 CAP, 4700pF
C1146 2113944C44 CAP, 91pF
C1147 2113944C05 CAP, 390pF
C1148 2113945C31 CAP, .1uF
C1149 2113944C46 CAP, 120pF
C1150 2113944C87 CAP, 130pF
C1151 NOT PLACED
C1152 NOT PLACED
C1153 NOT PLACED
C1201 2113945C31 CAP, .1uF
C1202 2313960D05 CAP, 4.7uF
C1203 2113945L49 CAP, .01uF
C1207 2113945C31 CAP, .1uF
C1209 2313960D07 CAP, 10uF
C1210 2113945C31 CAP, .1uF
C1211 2113945L49 CAP, .01uF
C1212 2313960B01 CAP, 1uF
C1213 2113945G95 CAP, .22uF
C1214 2113945C25 CAP, .033uF
C1215 2113944H37 CAP, 6800pF
C1216 2313960D05 CAP, 4.7uF
C1217 2113945L49 CAP, .01uF
C1218 2113945C31 CAP, .1uF
C1219 2313960D05 CAP, 4.7uF
C1220 2313960D05 CAP, 4.7uF
C1222 2113944C83 CAP, 36pF
C1223 2113945L49 CAP, .01uF
C1224 2113944C43 CAP, 82pF
C1225 2113945L49 CAP, .01uF
C1227 2113945L49 CAP, .01uF
C1229 2113945L49 CAP, .01uF
C1230 2113945L49 CAP, .01uF
C1231 2113945L49 CAP, .01uF
C1233 2113945L49 CAP, .01uF
C1234 2113945C31 CAP, .1uF
C1250 2313960C78 CAP, 2.2uF
C1251 2113945C31 CAP, .1uF
C1252 2113945C21 CAP, .018uF
C1253 2313960D05 CAP, 4.7uF
C1254 2113945L49 CAP, .01uF
C1306 2113944M23 CAP, 16pF
C1307 2113944M21 CAP, 13pF
C1308 2113944C22 CAP, 4.7pF
C1311 2113945L49 CAP, .01uF
C1312 2113945L49 CAP, .01uF
C1313 2113945L49 CAP, .01uF
C1314 2113944M21 CAP, 13pF
C1315 2113944M21 CAP, 13pF
C1316 2113944C18 CAP, 3.3pF
C1317 2113945C31 CAP, .1uF
Circuit
Ref
Motorola
Part No.
Description
C1318 2113945L49 CAP, .01uF
C1319 2113945L49 CAP, .01uF
C1320 2113945L49 CAP, .01uF
C1321 2113944C20 CAP, 3.9pF
C1323 2113944M21 CAP, 13pF
C1325 2113945L49 CAP, .01uF
C1326 2113945L49 CAP, .01uF
C1333 2113944M26 CAP, 22pF
C1334 2113944M31 CAP, 36pF
C1335 2113944C22 CAP, 4.7pF
C1336 2113945C31 CAP, .1uF
C1338 2113945L49 CAP, .01uF
C1339 2113945L49 CAP, .01uF
C1340 2113945L49 CAP, .01uF
C1341 2113944M31 CAP, 36pF
C1342 2113944M31 CAP, 36pF
C1343 2113944C18 CAP, 3.3pF
C1344 2113945L49 CAP, .01uF
C1345 2113945C31 CAP, .1uF
C1346 2113945L49 CAP, .01uF
C1347 2113945L49 CAP, .01uF
C1348 2113944C20 CAP, 3.9pF
C1349 2113945C31 CAP, .1uF
C1350 2113944C35 CAP, 27pF
C1351 2113945L49 CAP, .01uF
C1352 2113945L49 CAP, .01uF
C1401 2113945G45 CAP, .01uF
C1402 2113945G45 CAP, .01uF
C1404 2113945G45 CAP, .01uF
C1405 2113945G45 CAP, .01uF
C1407 2113945G45 CAP, .01uF
C1410 2113945G91 CAP, .1uF
C1412 2113944F73 CAP, 270pF
C1413 2113945G45 CAP, .01uF
C1414 2113945G45 CAP, .01uF
C1415 2113945G91 CAP, .1uF
C1417 2111078B58 CAP, 430pF
C1419 2113945G45 CAP, .01uF
C1420 2113945G45 CAP, .01uF
C1423 2113945G45 CAP, .01uF
C1424 2113945G45 CAP, .01uF
C1425 0871695L01 CAP, 1uF
C1426 0871695L01 CAP, 1uF
C1427 2111078B52 CAP, 240pF
C1428 2111078B52 CAP, 240pF
C1429 2111078B52 CAP, 240pF
C1430 2111078B52 CAP, 240pF
C1431 2113945G45 CAP, .01uF
C1432 0871695L01 CAP, 1uF
C1433 0871695L01 CAP, 1uF
C1434 2113945G45 CAP, .01uF
Circuit
Ref
Motorola
Part No.
Description
C1435 0871695L01 CAP, 1uF
C1436 2113945G45 CAP, .01uF
C1437 2111078B59 CAP, 470pF
C1438 2111078B59 CAP, 470pF
C1439 2111078B59 CAP, 470pF
C1440 2111078B59 CAP, 470pF
C1441 2111078B51 CAP, 220pF
C1442 2111078B44 CAP, 120pF
C1443 2111078B45 CAP, 130pF
C1444 2111078B45 CAP, 130pF
C1446 2180060M28 CAP, 24pF
C1447 2111078B59 CAP, 470pF
C1448 2111078B59 CAP, 470pF
C1449 2180060M44 CAP, 110pF
C1450 2180060M24 CAP, 16pF
C1451 2180060M49 CAP, 180pF
C1452 2180060M28 CAP, 24pF
C1453 2180060M46 CAP, 130pF
C1454 2180060M31 CAP, 33pF
C1455 2180060M24 CAP, 16pF
C1456 2180060M36 CAP, 51pF
C1457 2113945G45 CAP, .01uF
C1458 2314030J26 CAP, 10uF
C1459 2314030J26 CAP, 10uF
C1460 2113945C31 CAP, .1uF
C1461 2113945G45 CAP, .01uF
C1462 2314030J26 CAP, 10uF
C1463 211394600 CAP, 1.0uF
C1464 2113945G45 CAP, .01uF
C1465 211394600 CAP, 1.0uF
C1466 2113945G45 CAP, .01uF
C1467 2113944F62 CAP, 68pF
C1468 2113945G45 CAP, .01uF
C1469 0871695L01 CAP, 1uF
C1470 0871695L01 CAP, 1uF
C1471 2113945G45 CAP, .01uF
C1472 2113945G91 CAP, .1uF
C1473 2113945G91 CAP, .1uF
C1474 2113945G45 CAP, .01uF
C1475 0871695L01 CAP, 1uF
C1476 2113945G91 CAP, .1uF
C1477 2111078B54 CAP, 300pF
C1478 2111078B54 CAP, 300pF
C1479 2111078B51 CAP, 220pF
C1480 2111078B52 CAP, 240pF
C1481 2111078B52 CAP, 240pF
C1482 211394600 CAP, 1.0uF
C1484 2113945L33 CAP, 2200pF
C1485 2113945G45 CAP, .01uF
C1486 2113945G91 CAP, .1uF
C1501 2113945L33 CAP, 2200pF
Circuit
Ref
Motorola
Part No.
Description
C1502 2113945L33 CAP, 2200pF
C1503 2113945L33 CAP, 2200pF
C1504 2113945L33 CAP, 2200pF
C1505 2113945L25 CAP, 1000pF
C1506 2113945L25 CAP, 1000pF
C1507 2113945L33 CAP, 2200pF
C1508 2113945L33 CAP, 2200pF
C1509 2313960B01 CAP, 1uF
C1510 2113945L33 CAP, 2200pF
C1511 2113945L33 CAP, 2200pF
C1512 2113945L33 CAP, 2200pF
C1523 2113945C31 CAP, .1uF
C1525 2113945C31 CAP, .1uF
C1526 2113944C45 CAP, 100pF
C1527 2113945G45 CAP, .01uF
C1528 2113945G45 CAP, .01uF
C1530 2113945G45 CAP, .01uF
C1532 2113946J03 CAP, 10uF
C1601 2113945C31 CAP, .1uF
C1602 2113944C02 CAP, 220pF
C1603 2113945G95 CAP, .22uF
C1604 2113945G95 CAP, .22uF
C1605 2313960D07 CAP, 10uF
C1606 2113944C02 CAP, 220pF
C1607 2113944C45 CAP, 100pF
C1608 2113945G95 CAP, .22uF
C1609 2113944C80 CAP, 20pF
C1610 2113945L41 CAP, 4700pF
C1611 2113945C31 CAP, .1uF
C1612 2113945L33 CAP, 2200pF
C1613 2113944C87 CAP, 130pF
C1614 2113741F24 CAP, 910pF
C1616 2113944C83 CAP, 36pF
C1618 2113945G95 CAP, .22uF
C1619 2313960D07 CAP, 10uF
C1620 2113945L25 CAP, 1000pF
C1622 2113945C31 CAP, .1uF
C1623 2113944C90 CAP, 240pF
C1624 2113945L37 CAP, 3300pF
C1625 2113944C31 CAP, 12pF
C1626 2113944C02 CAP, 220pF
C1627 2113945G95 CAP, .22uF
C1628 2113945C31 CAP, .1uF
C1629 2113944C36 CAP, 33pF
C1631 2313960D07 CAP, 10uF
C1632 2113945C31 CAP, .1uF
C1633 2113945G95 CAP, .22uF
C1634 2113945G45 CAP, .01uF
CR1202 4802233J09 DIODE, TRIPLE
CR1302 4875058M01 DIODE VARACTOR
CR1306 4815048H01 DIODE MMBD353
Circuit
Ref
Motorola
Part No.
Description
