Motorola CP200XLS - Page 68

6-16 Mechanical View and Parts List
December, 2009 68009328001-A
Item
Motorola
Part
Number
Description
1 See Appendix
A
Antenna
2 3680530Z02 Knob, Frequency
3 1386440Z03 Escutcheon, Top
4 03012009001 Screw M1.6X.64
Self-tapping
5 15012016001 Housing, Full, with Lens
6 35012012001 Speaker, Felt
7 3886489Z02 PTT, Rubber
8 4586439Z01 PTT, Plastic
9 5005679X06 Speaker Assembly
10 42012006001 Retainer Speaker
11 3586621Z04 Felt, Microphone
12 05012002001 Boot, Microphone
13 0186639Z04 Microphone Plug Assembly
14 0104034J96 Display/Keypad Flex Circuit
Assembly - Full
16 1586437Z02 Shroud, Audio Jack
17 3286431Z05 Seal, Main O-ring
18 7586436Z02 Pad, PA Interface
19 2786389Z02 Chassis
20 3286435Z01 Seal, Battery Contact Block
21 0304726J05 Screws, Chassis; 4 Used
25 75012007001 Keypad, Full
26 5586445Z03 Latch Assembly
27 4116105H01 Spring, Latch; 2 Used
28 3886441Z02 Cap, Dust
29 3286432Z01 Seal, Control Shaft
30 0386434Z02 Screw, Speaker Retainer
31 3386443Z01 Label, Escutcheon Seal
32 6186446Z02 Lightpipe
33 3680529Z01 Knob, Volume
NON-REFERENCED ITEMS
54012047001 Nameplate, Motorola
Item
Motorola
Part
Number
Description
