REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N TYPE

SIDE LAY ADR

C 1098 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 B b2

C 1100 CHIP CAP. 100pF 50V CH GRM1552C1H101JA01D K22178236 B b2

C 1102 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 B c4

C 1104 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 B c4

C 1105 CHIP CAP. 0.015uF 16V B GRM155B11C153KA01D K22128807 B b2

C 1106 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 B c4

C 1107 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 B c4

C 1108 CHIP CAP. 22uF 6.3V B GRM21BB30J226ME38L K22080806 A C5

C 1109 CHIP CAP. 4.7uF 6.3V B C1608X5R0J475KT K22084805 A C6

C 1109 CHIP CAP. 4.7uF 6.3V X5R JMK107BJ475KA-T K22084809 A C6

C 1110 CHIP CAP. 4pF 50V CH GRM1552C1H4R0BA01D K22178291 B b2

C 1111 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 B b3

C 1112 CHIP CAP. 7pF 50V CH GRM1552C1H7R0BA01D K22178294 B b3

C 1113 CHIP CAP. 22pF 50V CH GRM1552C1H220GA01D K22179707 B c4

C 1114 CHIP CAP. 22uF 6.3V B GRM21BB30J226ME38L K22080806 A C5

C 1116 CHIP CAP. 6pF 50V CH GRM1552C1H6R0BA01D K22178293 B b3

C 1117 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 B b3

C 1120 CHIP CAP. 4.7uF 6.3V B C1608X5R0J475KT K22084805 A C5

C 1120 CHIP CAP. 4.7uF 6.3V X5R JMK107BJ475KA-T K22084809 A C5

C 1121 CHIP CAP. 4.7uF 6.3V B C1608X5R0J475KT K22084805 A C5

C 1121 CHIP CAP. 4.7uF 6.3V X5R JMK107BJ475KA-T K22084809 A C5

C 1122 CHIP CAP. 4.7uF 6.3V B C1608X5R0J475KT K22084805 A C5

C 1122 CHIP CAP. 4.7uF 6.3V X5R JMK107BJ475KA-T K22084809 A C5

C 1123 CHIP CAP. 5pF 50V CH GRM1552C1H5R0BA01D K22178292 B b3

C 1124 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BA01D K22178289 B b3

C 1125 CHIP CAP. 6pF 50V CH GRM1552C1H6R0BA01D K22178293 B b2

C 1128 CHIP CAP. 10pF 50V CH GRM1552C1H100JA01D K22178212 B c4

C 1129 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 A B2

C 1130 CHIP CAP. 10pF 50V CH GRM1552C1H100JA01D K22178212 B b4

C 1132 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 B b2

C 1134 CHIP CAP. 0.1uF 25V B GRM188B11E104KA01D K22144814 A C2

C 1136 CHIP CAP. 0.5pF 50V CK GRM1554C1HR50BA01D K22178285 B b3

C 1138 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 B b3

C 1139 CHIP CAP. 1.5pF 50V CK GRM1554C1H1R5BA01D K22178288 B b4

C 1140 CHIP TA.CAP. 4.7uF 10V TMCP1A475MTRF K78100073 A C2

C 1141 CHIP CAP. 47pF 50V CH GRM1552C1H470JA01D K22178228 B b3

C 1142 CHIP CAP. 100pF 50V CH GRM1552C1H101JA01D K22178236 B a2

C 1143 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 B a5

C 1144 CHIP CAP. 100pF 50V CH GRM1552C1H101JA01D K22178236 B b4

C 1145 CHIP CAP. 10uF 10V B GRM21BB31A106KE18L K22100808 A C5

C 1146 CHIP CAP. 10uF 10V B GRM21BB31A106KE18L K22100808 A C6

C 1147 CHIP CAP. 6pF 50V CH GRM1552C1H6R0BA01D K22178293 B b3

C 1148 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BA01D K22178289 B b3

C 1149 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 B b3

C 1150 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BA01D K22178289 B b3

C 1154 CHIP CAP. 680pF 50V B GRM155B11H681KA01D K22178807 A C2

C 1155 CHIP CAP. 680pF 50V B GRM155B11H681KA01D K22178807 A C2

C 1156 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 A C2

C 1157 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 A C2

C 1158 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 B a2

C 1159 CHIP CAP. 5pF 50V CH GRM1552C1H5R0BA01D K22178292 B b2

C 1163 CHIP CAP. 0.0022uF 50V B GRM155B11H222KA01D K22178813 B a2

C 1164 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 B a2

C 1165 CHIP TA.CAP. 10uF 16V F931C106MAA K78120095 A C2

C 1166 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 B a2

C 1167 CHIP CAP. 0.033uF 10V B GRM155B11A333KA01D K22108803 A C2

C 1168 CHIP CAP. 0.033uF 10V B GRM155B11A333KA01D K22108803 A C2

C 1169 CHIP CAP. 0.1uF 25V B GRM188B11E104KA01D K22144814 B a2

C 1170 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 B a2

C 1171 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 B a2

C 1172 CHIP CAP. 0.1uF 25V B GRM188B11E104KA01D K22144814 B a2

C 1173 CHIP CAP. 0.047uF 10V B GRM155B11A473KA01D K22108801 A C2

C 1174 CHIP CAP. 0.022uF 16V B GRM155B11C223KA01D K22128806 B a2

C 1175 CHIP CAP. 4.7uF 6.3V B C1608X5R0J475KT K22084805 A C2

C 1175 CHIP CAP. 4.7uF 6.3V X5R JMK107BJ475KA-T K22084809 A C2

C 1176 CHIP TA.CAP. 0.47uF 35V F931V474MAA K78160055 B a2

C 1177 CHIP CAP. 56pF 50V CH GRM0332C1H560JA01D K22177521 B a3

C 1179 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 A B2

C 1181 CHIP CAP. 0.001uF 25V B GRM033B11E102KA01D K22147712 A C3

C 1182 CHIP TA.CAP. 10uF 10V F921A106MAA K78100088 A B2

C 1183 CHIP CAP. 56pF 50V CH GRM0332C1H560JA01D K22177521 A C3

C 1184 CHIP CAP. 0.1uF 10V B LMK063BJ104KP-F K22107707 B a2

C 1185 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 A C4

C 1186 CHIP CAP. 0.1uF 10V B LMK063BJ104KP-F K22107707 A C3

C 1187 CHIP CAP. 0.1uF 10V B LMK063BJ104KP-F K22107707 A C3

C 1188 CHIP CAP. 0.1uF 10V B LMK063BJ104KP-F K22107707 A C3

C 1189 CHIP CAP. 0.1uF 10V B LMK063BJ104KP-F K22107707 A C3

C 1190 CHIP CAP. 0.1uF 10V B LMK063BJ104KP-F K22107707 A C3

C 1191 CHIP CAP. 0.1uF 10V B LMK063BJ104KP-F K22107707 A C2

MN006437A01-AB
