Motorola EVX S24

7.1
Display Unit Parts List
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N TYPE SIDE LAY ADR
PCB with Component
CB7125000
(
BLK
)
C 2002 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 B c4
C 2003 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 B b2
C 2004 CHIP CAP. 0.1uF 25V B GRM188B11E104KA01D K22144814 B b2
C 2006 CHIP CAP. 10uF 10V B GRM21BB31A106KE18L K22100808 B c3
C 2010 CHIP CAP. 10uF 10V B GRM21BB31A106KE18L K22100808 B b2
C 2011 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 B b2
C 2013 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 B c1
C 2014 CHIP CAP. 0.1uF 25V B GRM188B11E104KA01D K22144814 B c1
C 2018 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 B b1
C 2019 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 B a1
C 2020 CHIP CAP. 390pF 50V B GRM155B11H391KA01D K22178804 B a1
C 2021 CHIP CAP. 390pF 50V B GRM155B11H391KA01D K22178804 B a1
C 2022 CHIP CAP. 390pF 50V B GRM155B11H391KA01D K22178804 B a1
C 2023 CHIP CAP. 390pF 50V B GRM155B11H391KA01D K22178804 B b1
C 2024 CHIP CAP. 390pF 50V B GRM155B11H391KA01D K22178804 B b3
C 2025 CHIP CAP. 390pF 50V B GRM155B11H391KA01D K22178804 B c1
C 2026 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 B b3
C 2027 CHIP CAP. 390pF 50V B GRM155B11H391KA01D K22178804 B c3
D 2001 LED 12-21UYOC/S530-A3/TR8 G2071581 A A1
D 2002 LED 12-21UYOC/S530-A3/TR8 G2071581 A B1
D 2003 LED 12-21UYOC/S530-A3/TR8 G2071581 A B1
D 2004 LED 12-21UYOC/S530-A3/TR8 G2071581 A C1
D 2005 LED HSML-C191 G2071358 A B3
D 2006 LED HSML-C191 G2071358 A C3
D 2008 DIODE 1SS400G T2R G2070934 B c3
DS2001 LCD GTA4716SY01 G6090231 A B2
J 2002 SPACER RA1239400 B c3
J 2003 SPACER RA1239400 B a3
J 2004 CONNECTOR FH34SRJ-20S-0.5SH(50) P1091573 B c3
MC2001 MICROPHONE ELEMENT PFO-T6022P-1.5 M3290060 A A4
Q 2001 TRANSISTOR 2SC4617 TL R G3346178R B c1
Q 2002 TRANSISTOR 2SC4617 TL R G3346178R B a1
Q 2003 TRANSISTOR 2SC4617 TL R G3346178R B b3
Q 2004 IC BU9795AKV-E2 G1095483 B b1
R 2001 CHIP RES. 1k 1/16W 1% RMC1/16SK102FTH J24189487 B c3
R 2002 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 B c1
R 2003 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 B b1
R 2005 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 B b1
R 2006 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 B a1
R 2007 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 B c3
R 2008 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 B b3
R 2009 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 B b3
R 2010 CHIP RES. 2.2k 1/16W 1% RMC1/16SK222FTH J24189497 B c3
R 2011 CHIP RES. 220 1/16W 1% RMC1/16SK221FTH J24189508 B c3
R 2012 CHIP RES. 47k 1/16W 1% RMC1/16SK473FTH J24189525 B b2
R 2013 CHIP RES. 1k 1/16W 1% RMC1/16SK102FTH J24189487 B c3
R 2014 CHIP RES. 1k 1/16W 1% RMC1/16SK102FTH J24189487 B c3
R 2015 CHIP RES. 1k 1/16W 1% RMC1/16SK102FTH J24189487 B c3
R 2016 CHIP RES. 1k 1/16W 1% RMC1/16SK102FTH J24189487 B c3
R 2017 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 B c3
R 2018 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 B b3
R 2020 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 B b2
R 2021 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 B b3
R 2022 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 B c4
R 2023 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 B c4
R 2024 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 B b3
R 2025 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 B a3
R 2027 CHIP RES. 8.2k 1/16W 1% RMC1/16SK822FTH J24189522 B c1
R 2028 CHIP RES. 8.2k 1/16W 1% RMC1/16SK822FTH J24189522 B a1
R 2029 CHIP RES. 8.2k 1/16W 1% RMC1/16SK822FTH J24189522 B b3
R 2030 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 B c1
R 2032 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 B a1
R 2034 CHIP RES. 56 1/16W 5% RMC1/16S 560JTH J24189010 B b3
S 2001 TACT SWITCH SKRMABE010 N5090172 A A3
S 2002 TACT SWITCH SKRMABE010 N5090172 A B3
S 2003 TACT SWITCH SKRMABE010 N5090172 A C3
LIGHT GUIDE (LCD) RA1631200
HOLDER (LCD) RA1631300
REFLECTOR SHEET RA163140A
DOUBLE FACE ADHESIVE (LCD) RA1631500
INTER CONNECTOR RA1631600
SPACER (MIC) RA1561000
MN006437A01-AB
Chapter 7: Display Unit (FR028310A)
49
