Main Unit Parts List (FR028210D)

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N TYPE

SIDE LAY ADR

PCB with Component CB7203000

C 1001 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 A B1

C 1002 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 A B1

C 1003 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 A C1

C 1004 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 B a5

C 1006 CHIP CAP. 1uF 10V B GRM155B31A105KE15D K22108809 B c4

C 1007 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 B c1

C 1008 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BA01D K22178289 B c1

C 1009 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 B c5

C 1010 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BA01D K22178289 B c1

C 1011 CHIP CAP. 1uF 10V B GRM155B31A105KE15D K22108809 B c5

C 1012 CHIP CAP. 4pF 50V CH GRM1552C1H4R0BA01D K22178291 B c1

C 1013 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 A A1

C 1014 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 A A1

C 1015 CHIP CAP. 5pF 50V CH GRM1552C1H5R0BA01D K22178292 B c1

C 1017 CHIP CAP. 2.5pF 50V CH GRM1552C1H2R5BA01D K22179729 B c1

C 1019 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 A A1

C 1022 CHIP CAP. 3pF 50V CJ GRM1553C1H3R0BA01D K22178290 B c2

C 1023 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 A A1

C 1026 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DA01D K22174209 B c2

C 1027 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CA01D K22174206 B c2

C 1028 CHIP CAP. 4pF 50V CH GRM1552C1H4R0BA01D K22178291 B c2

C 1029 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CA01D K22174204 B c2

C 1032 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 B b5

C 1033 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 B b5

C 1034 CHIP CAP. 100pF 50V CH GRM1552C1H101JA01D K22178236 B c2

C 1036 CHIP CAP. 18pF 50V CH GRM1882C1H180JA01D K22174217 B c2

C 1037 CHIP CAP. 9pF 50V CH GRM1882C1H9R0CA01D K22174247 B c2

C 1038 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 B c2

C 1040 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 B c2

C 1041 CHIP CAP. 0.1uF 25V B GRM188B11E104KA01D K22144814 B c2

C 1042 CHIP CAP. 3pF 50V CJ GRM1553C1H3R0BA01D K22178290 B c2

C 1043 CHIP TA.CAP. 4.7uF 25V F921E475MAA K78140036 A B2

C 1044 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 B a4

C 1045 CHIP CAP. 8pF 50V CH GRM1552C1H8R0BA01D K22178295 B c2

C 1047 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 A B2

C 1048 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 A A6

C 1049 CHIP TA.CAP. 10uF 10V TMCP1A106MTRF K78100074 A A6

C 1051 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 B a5

C 1052 CHIP CAP. 150pF 50V CH GRM1882C1H151JA01D K22174239 B b5

C 1053 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 A A2

C 1054 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 A B2

C 1055 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 B a5

C 1056 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 B b5

C 1057 CHIP CAP. 4pF 50V CH GRM1552C1H4R0BA01D K22178291 B c2

C 1058 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 A A3

C 1059 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 A A2

C 1060 CHIP CAP. 10uF 25V B GRM31CB31E106KA75L K22141815 B a5

C 1061 CHIP CAP. 0.022uF 16V B GRM155B11C223KA01D K22128806 A A3

C 1062 CHIP CAP. 0.0022uF 50V B GRM155B11H222KA01D K22178813 A A2

C 1066 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 A A3

C 1067 CHIP CAP. 8pF 50V CH GRM1552C1H8R0BA01D K22178295 B b2

C 1068 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 A B2

C 1069 CHIP CAP. 1uF 25V B GRM188B31E105KA75D K22144815 B c3

C 1070 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 A A3

C 1071 CHIP CAP. 3pF 50V CJ GRM1553C1H3R0BA01D K22178290 B b2

C 1072 CHIP CAP. 12pF 50V CH GRM1552C1H120GA01D K22179723 B c3

C 1073 CHIP CAP. 27pF 50V CH GRM1552C1H270GA01D K22179726 B c3

C 1075 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 B c3

C 1077 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 A C2

C 1078 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 A B2

C 1079 CHIP CAP. 1uF 25V B GRM188B31E105KA75D K22144815 B c3

C 1080 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 B a2

C 1081 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 B c3

C 1082 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 B c4

C 1083 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 A B1

C 1084 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 A A3

C 1085 CHIP CAP. 27pF 50V CH GRM1552C1H270GA01D K22179726 B c3

C 1086 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 A A2

C 1087 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 B a4

C 1089 CHIP CAP. 0.047uF 10V B GRM155B11A473KA01D K22108801 B c4

C 1090 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 B c4

C 1091 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 A A2

C 1092 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 B b5

C 1093 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 B b2

C 1094 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 A B1

C 1095 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 B b4

C 1096 CHIP CAP. 10pF 50V CH GRM1552C1H100JA01D K22178212 B c4

C 1097 CHIP CAP. 12pF 50V CH GRM1552C1H120GA01D K22179723 B c4
