Motorola EVX S24

8.1
Main Unit Parts List (PC003006A01)
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG Part No. SIDE LAY ADR
C1001 CHIP CAP. 0.1uF 10V B OBS-LMK105BJ104KV-F K22108802 A B1
C1002 CHIP CAP. 0.1uF 10V B OBS-LMK105BJ104KV-F K22108802 A B1
C1003 CHIP CAP. 0.1uF 10V B OBS-LMK105BJ104KV-F K22108802 A B1
C1004 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 B a5
C1006 CHIP CAP. 1uF 10V B OBS-LMK105BJ105KV-F K22108809 B c4
C1007 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 B c1
C1008 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BA01D K22178289 B c1
C1009 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 B a5
C1010 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BA01D K22178289 B c1
C1011 CHIP CAP. 1uF 10V B OBS-LMK105BJ105KV-F K22108809 B c4
C1012 CHIP CAP. 4pF 50V CH GRM1552C1H4R0BA01D K22178291 B c1
C1013 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 B c1
C1014 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 A A1
C1015 CHIP CAP. 5pF 50V CH K22178292 K22178292 B
c1
C1017 CHIP CAP. 2.5pF 50V CH K22179729 K22179729 B c1
C1019 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 A A1
C1022 CHIP CAP. 3pF 50V CJ GRM1553C1H3R0BA01D K22178290 B c2
C1023 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 B c1
C1026 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DA01D K22174209 B c2
C1027 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CA01D K22174206 B c2
C1028 CHIP CAP. 4pF 50V CH GRM1552C1H4R0BA01D K22178291 B c1
C1029 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CA01D K22174204 B c2
C1032 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 B b5
C1033 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 B b5
C1034 CHIP CAP. 100pF 50V CH GRM1552C1H101JA01D K22178236 B c2
C1036 CHIP CAP. 18pF 50V CH GRM1882C1H180JA01D K22174217 B c2
C1037 CHIP CAP. 9pF 50V CH GRM1882C1H9R0CA01D K22174247 B c2
C1038 CHIP CAP. 220pF 50V CH OBS-UMK105CH221JV-F K22179713 B c2
C1040 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240
Bc1
C1041 CHIP CAP. 0.1uF 25V B 06033C104KAT2A K22144814 B c2
C1042 CHIP CAP. 3pF 50V CJ GRM1553C1H3R0BA01D K22178290 B c2
C1043 CHIP TA.CAP. 4.7uF 25V F921E475MAA K78140036 A B2
C1044 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 A A1
C1045 CHIP CAP. 8pF 50V CH GRM1552C1H8R0BA01D K22178295 B c2
C1047 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 A A1
C1048 CHIP CAP. 0.1uF 10V B OBS-LMK105BJ104KV-F K22108802 A B1
C1049 CHIP TA.CAP. 10uF 10V TMCP1A106MTRF K78100074 A A6
C1051 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 B b5
C1052 CHIP CAP. 150pF 50V CH GRM1882C1H151JA01D K22174239 B b5
C1053 CHIP CAP. 220pF 50V CH OBS-UMK105CH221JV-F K22179713 B c2
C1054 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 B c1
C1055 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 B a5
C1056 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 A A1
C1057 CHIP CAP. 4pF 50V CH GRM1552C1H4R0BA01D K22178291 B
c1
C1058 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 B c1
C1059 CHIP CAP. 220pF 50V CH OBS-UMK105CH221JV-F K22179713 B c2
MN006437A01-AB
Chapter 8: Main Unit (PC003006A01)
54
