REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N TYPE

SIDE LAY ADR

C 1276 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 A B3

C 1284 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 A B1

C 1285 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 A B2

C 1286 CHIP CAP. 18pF 50V CH GRM1882C1H180JA01D K22174217 B c2

C 1288 CHIP CAP. 1pF 50V CK GRM1554C1H1R0BA01D K22178287 B b3

C 1289 CHIP CAP. 1uF 10V B GRM155B31A105KE15D K22108809 B a5

C 1290 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 B a5

C 1291 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 B b5

C 1292 CHIP CAP. 2.2uF 6.3V B GRM155B30J225KE95D K22088805 B a5

C 1293 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 B a4

C 1296 CHIP TA.CAP. 10uF 16V F931C106MAA K78120095 A C2

C 1297 CHIP CAP. 1uF 10V B GRM155B31A105KE15D K22108809 A B1

C 1299 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 B a4

C 1304 CHIP CAP. 1uF 10V B GRM155B31A105KE15D K22108809 A C2

C 1305 CHIP CAP. 390pF 50V B GRM155B11H391KA01D K22178804 A B2

C 1306 CHIP CAP. 390pF 50V B GRM155B11H391KA01D K22178804 B b2

C 1307 CHIP CAP. 390pF 50V B GRM155B11H391KA01D K22178804 B b2

C 1309 CHIP CAP. 390pF 50V B GRM155B11H391KA01D K22178804 B b2

C 1310 CHIP CAP. 390pF 50V B GRM155B11H391KA01D K22178804 A C5

C 1311 CHIP CAP. 390pF 50V B GRM155B11H391KA01D K22178804 A C6

C 1314 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 A C5

C 1316 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 A C6

C 1317 CHIP CAP. 1uF 10V B GRM155B31A105KE15D K22108809 A C5

C 1323 CHIP CAP. 1uF 10V B GRM155B31A105KE15D K22108809 A C3

C 1325 CHIP CAP. 1.5pF 50V CK GRM1554C1H1R5BA01D K22178288 B b3

C 1326 CHIP CAP. 47pF 50V CH GRM1552C1H470GA01D K22179709 B c2

C 1327 CHIP CAP. 47pF 50V CH GRM1552C1H470GA01D K22179709 B b2

C 1330 CHIP CAP. 100pF 50V CH GRM1552C1H101JA01D K22178236 B b2

C 1331 CHIP CAP. 47pF 50V CH GRM1552C1H470GA01D K22179709 B a2

C 1332 CHIP CAP. 4pF 50V CH GRM1552C1H4R0BA01D K22178291 B a2

C 1333 CHIP CAP. 47pF 50V CH GRM1552C1H470GA01D K22179709 B a2

C 1334 CHIP CAP. 15pF 50V CH GRM1552C1H150GA01D K22178300 B a2

C 1336 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BA01D K22178289 B a2

C 1337 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 A A1

C 1338 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 A A1

C 1339 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 A A1

C 1340 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 A A1

C 1341 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 A A1

C 1342 CHIP CAP. 1uF 10V B GRM155B31A105KE15D K22108809 A A1

C 1343 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 A C5

C 1344 CHIP CAP. 0.0022uF 50V B GRM155B11H222KA01D K22178813 A C5

C 1345 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 A C1

C 1346 CHIP CAP. 4.7uF 6.3V B C1608X5R0J475KT K22084805 A A3

C 1346 CHIP CAP. 4.7uF 6.3V X5R JMK107BJ475KA-T K22084809 A A3

C 1347 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 A B1

C 1348 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 A B3

C 1350 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 A B2

C 1351 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 A B2

C 1352 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 A B2

C 1353 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 A B1

C 1354 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DA01D K22174207 B c2

C 1355 CHIP CAP. 27pF 50V CH GRM1882C1H270JA01D K22174221 B c2

C 1356 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 B a5

C 1357 CHIP CAP. 1uF 10V B GRM155B31A105KE15D K22108809 B a5

C 1360 CHIP CAP. 0.0022uF 50V B GRM155B11H222KA01D K22178813 A C2

C 1361 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 A C2

C 1362 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 A C2

C 1363 CHIP CAP. 0.0068uF 25V B GRM155B11E682KA01D K22148803 A C5

C 1369 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 B a5

C 1370 CHIP CAP. 1uF 10V B GRM155B31A105KE15D K22108809 A B1

C 1371 CHIP CAP. 0.0082uF 16V B GRM155B11C822KA01D K22128801 B b1

C 1371 CHIP CAP. 0.0033uF 50V B GRM155B11H332KA01D K22178815 B b1

C 1372 CHIP CAP. 0.068uF 16V B GRM155B31C683KA87D K22128815 B c1

C 1372 CHIP CAP. 0.033uF 10V B GRM155B11A333KA01D K22108803 B c1

C 1373 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 B c1

C 1373 CHIP CAP. 0.0068uF 25V B GRM155B11E682KA01D K22148803 B c1

C 1374 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 B c1

C 1375 CHIP CAP. 1uF 10V B GRM155B31A105KE15D K22108809 B c2

C 1376 CHIP TA.CAP. 10uF 16V F931C106MAA K78120095 A C2

C 1377 CHIP TA.CAP. 1uF 16V TMCP1C105MTRF K78120076 A C5

C 1601 CHIP CAP. 10uF 6.3V B JMK212BJ106KG-T K22080802 B b4

C 1602 CHIP CAP. 0.1uF 10V B LMK063BJ104KP-F K22107707 B b4

C 1603 CHIP CAP. 0.1uF 10V B LMK063BJ104KP-F K22107707 B b4

C 1604 CHIP CAP. 0.1uF 10V B LMK063BJ104KP-F K22107707 A A4

C 1605 CHIP CAP. 0.1uF 10V B LMK063BJ104KP-F K22107707 A A5

C 1606 CHIP CAP. 0.1uF 10V B LMK063BJ104KP-F K22107707 A A4

C 1607 CHIP CAP. 0.1uF 10V B LMK063BJ104KP-F K22107707 A A5

C 1608 CHIP CAP. 0.1uF 10V B LMK063BJ104KP-F K22107707 A A5

C 1609 CHIP CAP. 150pF 25V B GRM033B11E151KA01D K22147702 A A4

MN006437A01-AB
