Motorola EVX S24 User Manual

Conducted Spurious: –57 dBm
Audio output: 500 mW @4 Ohm, <10 % THD
Table 3: Transmitter (Measured by TIA/EIA-603)
Output Power: 3/1/0.5 W (Digital)
2/1/0.5 W (Analog)
Modulation: Sigma Delta Modulation
Maximum Frequency Deviation: ±5.0 kHz (25 kHz Step, Analog)
±2.5 kHz (12.5 kHz Step, Analog)
Conducted Spurious Emissions: –36 dBm @<= 1 GHz, –30 dBm @> 1 GHz
FM Hum & Noise: 45 dB (25 kHz)
40 dB (12.5 kHz)
Audio Distortion: <5% @1 kHz
MN006437A01-AB
Chapter 2: Specifications : USA (NA)
5

Motorola EVX S24 Specifications

General

Frequency Range	VHF: 136-174 MHz, UHF: 403-470 MHz
IP Rating	IP67
Operating Temperature	-30°C to +60°C
Digital Protocol	DMR
Programmable Buttons	2
Channels	256
Display	Yes
