Motorola EVX S24

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG Part No. SIDE LAY ADR
C1299 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 B b5
C1305 CHIP CAP. 390pF 50V B GRM155B11H391KA01D K22178804 A C3
C1306 CHIP CAP. 390pF 50V B GRM155B11H391KA01D K22178804 A C3
C1307 CHIP CAP. 390pF 50V B GRM155B11H391KA01D K22178804 A C3
C1309 CHIP CAP. 390pF 50V B GRM155B11H391KA01D K22178804 A C3
C1310 CHIP CAP. 390pF 50V B GRM155B11H391KA01D K22178804 A C3
C1311 CHIP CAP. 390pF 50V B GRM155B11H391KA01D K22178804 A C3
C1314 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 B a5
C1316 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 B a5
C1317 CHIP CAP. 1uF 10V B OBS-LMK105BJ105KV-F K22108809 B c4
C1323 CHIP CAP. 1uF 10V B OBS-LMK105BJ105KV-F K22108809 B c4
C1325 CHIP CAP. 1.5pF 50V CK GRM1554C1H1R5BA01D K22178288 B b4
C1326 CHIP CAP. 47pF 50V CH GRM1552C1H470GA01D K22179709 B c2
C1327 CHIP CAP. 47pF 50V CH GRM1552C1H470GA01D K22179709 B
c2
C1330 CHIP CAP. 100pF 50V CH GRM1552C1H101JA01D K22178236 B c2
C1331 CHIP CAP. 47pF 50V CH GRM1552C1H470GA01D K22179709 B c2
C1332 CHIP CAP. 4pF 50V CH GRM1552C1H4R0BA01D K22178291 B c1
C1333 CHIP CAP. 47pF 50V CH GRM1552C1H470GA01D K22179709 B c2
C1334 CHIP CAP. 15pF 50V CH K22178300 K22178300 B a2
C1336 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BA01D K22178289 B c1
C1337 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 B c1
C1338 CHIP CAP. 0.1uF 10V B OBS-LMK105BJ104KV-F K22108802 A B1
C1339 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 A A1
C1340 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 B c1
C1341 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 A A1
C1342 CHIP CAP. 1uF 10V B OBS-LMK105BJ105KV-F K22108809 B c4
C1343 CHIP CAP. 0.1uF 10V B OBS-LMK105BJ104KV-F K22108802 A B1
C1344 CHIP CAP. 0.0022uF 50V B GRM155B11H222KA01D K22178813 A A2
C1345 CHIP CAP. 0.1uF 10V B OBS-LMK105BJ104KV-F K22108802
AB1
C1346 CHIP CAP. 4.7uF 6.3V X5R JMK107BJ475KA-T K22084809 A C6
C1347 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 A A1
C1348 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 B b5
C1350 CHIP CAP. 220pF 50V CH OBS-UMK105CH221JV-F K22179713 B c2
C1351 CHIP CAP. 220pF 50V CH OBS-UMK105CH221JV-F K22179713 B c2
C1354 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DA01D K22174207 B c2
C1355 CHIP CAP. 27pF 50V CH GRM1882C1H270JA01D K22174221 B c2
C1356 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 B b5
C1357 CHIP CAP. 1uF 10V B OBS-LMK105BJ105KV-F K22108809 B c4
C1360 CHIP CAP. 0.0022uF 50V B GRM155B11H222KA01D K22178813 A A2
C1361 CHIP CAP. 0.47uF 16V X5R GRT155R61C474KE01D CA002214A01 A C2
C1363 CHIP CAP. 0.0068uF 25V B K22148803 K22148803 A C5
C1364 NOTPLACED A B1
C1365 NOTPLACED A B1
C1369 CHIP CAP. 0.1uF 10V B OBS-LMK105BJ104KV-F K22108802 A B1
C1370 CHIP CAP. 1uF 10V B OBS-LMK105BJ105KV-F K22108809
Bc4
C1371 CHIP CAP. 0.0033uF 50V B GRM155B11H332KA01D K22178815 B b1
MN006437A01-AB
Chapter 8: Main Unit (PC003006A01)
59
