Motorola EVX S24

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG Part No. SIDE LAY ADR
FB1601 FERRITE BEADS L9190127 L9190127 A A5
FB1602 FERRITE BEADS L9190127 L9190127 A A5
FB1603 FERRITE BEADS L9190127 L9190127 A A5
FB1604 FERRITE BEADS L9190127 L9190127 A A5
FB1605 FERRITE BEADS L9190127 L9190127 A A5
HS1001 PLATE RA1468800 RA1468800 B c3
J1001 CONTACT 10F00B35011-P P0091593 B c6
J1002 CONTACT 10F00B35011-P P0091593 B c6
J1003 CONNECTOR ZX62D-B-5PA8(30) P1091565 B c5
J1004 CONNECTOR 47410-0001 P0091591 B c5
J1005 CONNECTOR 03-A70G0-36BKA P1091581 B b1
J1008 CONNECTOR FH34SRJ-20S-0.5SH(50) P1091573 A B3
J1009 CONTACT 10F00B35011-P P0091593 B c6
J1010 CONTACT 10F00B35011-P P0091593 B c6
J1601 CONNECTOR CONNECTOR AXT516124 P1091482 A B5
L1001 M.RFC 0.0147uH 0.02 0908SQ-14NGLC L1691837 B c1
L1002 M.RFC 0.0147uH 0.02 0908SQ-14NGLC L1691837 B c1
L1003 M.RFC 0.39uH 0.02 L1691617 L1691617 A A1
L1004 M.RFC 0.0166uH 0.02 0908SQ-17NGLC L1691839 B c2
L1005 COIL 0.0033uH
ASS050221-3R3NJ L0022635 B c2
L1006 M.RFC 0.056uH LGHK160856NJ-T L1690525 B c2
L1007 COIL 0.047uH ASS030821-51R0NJ L0022824 B c2
L1008 M.RFC 0.022uH 0.02 L1691602 L1691602 B c2
L1009 COIL 24nH 0603HP-24NXGLW 2478057A26 B B2
L1011 M.RFC 0.0022uH LGHK16082N2S-T L1690508 B c3
L1012 M.RFC 0.0068uH 0.02 0603HP-6N8XGLW L1691596 B c3
L1013 M.RFC 0.015uH L1690518 L1690518 B c4
L1014 COIL 20nH 0402HP-20NXGLW 2478390A22 B C2
L1015 M.RFC 0.22uH 0402HPH-R22XGLW L1691967 B b2
L1016 M.RFC 0.015uH L1690518 L1690518 B c4
L1017 M.RFC 0.0047uH 0402HP-4N7XGLW L1691879 B b3
L1018 RESONATOR SDRF1250S02F08PA Q9000995 B b3
L1019 M.RFC 0.027uH LGHK160827NJ-T L1690521 B b2
L1020 M.RFC 0.022uH 0.02 L1691602 L1691602 B c2
L1021 M.RFC 0.22uH 0402HPH-R22XGLW L1691967 B b2
L1022 M.RFC 0.22uH 0402HPH-R22XGLW L1691967 B b2
L1023 M.RFC 0.022uH 0.02 L1691602 L1691602 B c2
L1025 M.RFC 0.018uH 0.02 0603HP-18NXGLW L1691601 B b4
L1026 M.RFC 1uH 0.05 L1691457 L1691457 A C5
L1027 M.RFC 1uH 0.05 L1691457 L1691457 A C5
L1028 M.RFC 0.018uH L1690519 L1690519 B b3
L1029 M.RFC 0.0068uH LGHK16086N8J-T L1690514 B b3
L1031 M.RFC 10uH L1690689 L1690689 A C3
L1032 M.RFC 0.022uH HK1005 22NJ-T L1691381 B b2
L1033 M.RFC 0.033uH LGHK100533NJ-T L1691383 B b2
L1034 M.RFC 0.022uH 0.02 L1691602 L1691602 B c2
MN006437A01-AB
Chapter 8: Main Unit (PC003006A01)
64
