Motorola EVX S24

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG Part No. SIDE LAY ADR
R1630 CHIP RES. 22 1/16W 0.05 RMC1/16S-220JTH J24189005 A A5
R1631 CHIP RES. 0 1/16W 0.05 RMC1/16SJPTH J24189070 A B2
R1632 CHIP RES. 0 1/16W 0.05 RMC1/16SJPTH J24189070 A B2
R1633 CHIP RES. 0 1/16W 0.05 RMC1/16SJPTH J24189070 A B2
R1634 CHIP RES. 10k 1/16W 0.01 J24189489 J24189489 B c5
R1635 CHIP RES. 4.7k 1/20W 0.05 RMC1/20 472JPA J24175472 A B4
R1636 CHIP RES. 4.7k 1/20W 0.05 RMC1/20 472JPA J24175472 A B4
R1639 CHIP RES. 2.2k 1/16W 0.01 RMC1/16SK222FTH J24189497 A B2
R1642 CHIP RES. 4.7k 1/20W 0.05 RMC1/20 472JPA J24175472 A B4
R1643 CHIP RES. 100 1/20W 0.05 RMC1/20-101JPA J24175101 A B5
R1644 CHIP RES. 4.7k 1/20W 0.05 RMC1/20 472JPA J24175472 A B4
R1645 CHIP RES. 100 1/20W 0.05 RMC1/20-101JPA J24175101 A B5
R1646 CHIP RES. 4.7k 1/20W 0.05 RMC1/20 472JPA J24175472 A B4
R1647 CHIP RES. 100 1/20W 0.05 RMC1/20-101JPA J24175101 A
B5
R1648 CHIP RES. 4.7k 1/20W 0.05 RMC1/20 472JPA J24175472 A B4
R1649 CHIP RES. 1k 1/20W 0.05 RMC1/20-102JPA J24175102 B a3
R1650 CHIP RES. 4.7k 1/20W 0.05 RMC1/20 472JPA J24175472 A B4
R1651 CHIP RES. 4.7k 1/20W 0.05 RMC1/20 472JPA J24175472 A B4
R1652 CHIP RES. 100 1/20W 0.05 RMC1/20-101JPA J24175101 A B5
R1653 CHIP RES. 4.7k 1/20W 0.05 RMC1/20 472JPA J24175472 A B4
R1655 CHIP RES. 0 1/20W 0.05 RMC1/20JPPA J24175000 B a3
R1661 CHIP RES. 10k 1/16W 0.01 J24189489 J24189489 B c5
R1664 CHIP RES. 0 1/16W 0.05 RMC1/16SJPTH J24189070 A B2
R1667 CHIP RES. 0 1/16W 0.05 RMC1/16SJPTH J24189070 A B2
R1669 CHIP RES. 10k 1/16W 0.01 J24189489 J24189489 B c5
R1670 CHIP RES. 10k 1/16W 0.01 J24189489 J24189489 B c5
R1674 CHIP RES. 10k 1/16W 0.01 RK73H1ETTP1002F 0613952N01 A B4
R1675 CHIP RES. 33 1/20W 0.05 RMC1/20 330JPA J24175330 A C4
R1700 CHIP RES. 0 0.05 ERJ2GE0R00X 0613952R66 A
C2
R1701 CHIP RES. 1k 1/16W 0.01 RC0402FR-071KL 0613952M01 A C1
R1702 CHIP RES. 10k 1/16W 0.01 ERJ1GEF103C 0613952V01 A C1
R1703 CHIP RES. 47k 0.05 RK73B1HTTC473J 0613952Y17 A C2
R1705 CHIP RES. 1k 1/16W 0.01 RMC1/16SK102FTH J24189487 B c4
R1706 NOTPLACED A C2
R1707 NOTPLACED A C2
R1708 CHIP RES. 5.6k 1/16W 0.01 J24189520 J24189520 B c5
R1709 NOTPLACED A C2
R1711 NOTPLACED A C2
R1712 CHIP RES. 0 1/16W 0.05 ERJ2GE0R00X 0613952R66 A C2
R1713 NOTPLACED A C2
R1714 CHIP RES. 1.8k 1/16W 0.01 RMC1/16SK182FTH 0613952Z39 A C2
S1001 TACT SWITCH N5090176 N5090176 B c3
S1002 TACT SWITCH N5090176 N5090176 B c3
SC1001 SHIELD CASE PRA1635000 RA1635000 B b3
SC1002 SHIELD CASE BA1644800 RA1644800 A A3
SC1601 SHIELD CASE BA163490A RA163490A A B4
MN006437A01-AB
Chapter 8: Main Unit (PC003006A01)
73
