A. Recommended Test Equipment
The list of equipment contained in Table 40-1
includes all of the standard test equipment required for
servicing two-way portable radios, as well as several
unique items designed specifically for servicing this fam-
ily of radios. Battery-operated test equipment is
recommended when available. The "CHARACTERIS-
TICS" column is included so that equivalent equipment
may be substituted; however, when no information is
provided in this column, the specific Motorola model list-
ed is either a unique item or no substitution is
recommended.
B. Service Aids and Recommended Tools
Refer to the “SERVICE AIDS” in Table 40-2 and
“RECOMMENDED TOOLS LIST” in Table 40-3 for a
listing and description of the service aids and tools
designed specifically for servicing this family of radios,
as well as the more common tools required to disas-
semble and properly maintain the radio. These kits
and/or parts are available from the Motorola Communi-
cations Parts office listed in the “Replacement Parts
Ordering” section of this manual.
MAV-PACK 3 (VID-952)/F.A.S.T. 60
The VID-952 Motorola Video Visual Package (MAV-
PACK) is a video tape training program on leadless
component repair techniques. This VHS format video
cassette and supplemental literature describe the
removal and replacement of leadless components using
the R-1070A surface-mounted IC removal station:
• 0180386A62 Heated Tweezers
• 0180356B79 Desoldering Station
• 0180371B30 Soldering Station
This MAV-PACK is strongly recommended for tech-
nicians who intend to service this and other Motorola
radios using leadless components. This VHS videotape
is in standard half-inch format.
National Service Training’s Field Assist Service
Training (F.A.S.T.) Video Tape #60 introduces this
family of radios. Included on this tape are basic theory
of operation, disassembly, and basic troubleshooting
techniques.
The MAV-PACK 3 (VID-952), as well as others, and
the F.A.S.T. 60 are available from:
Motorola C&E, Inc.
National Service Training Center
1300 N. Plum Grove Road
Schaumburg, Illinois 60195
C. Field Programming
This family of radios can be aligned and pro-
grammed in the field. This requires specific equipment
and special instructions. Refer to the applicable “Radio
Service Software User's Manual” for complete field
programming information.
SECTION II. RECOMMENDED AND REQUIRED TEST EQUIPMENT,
SERVICE AIDS, AND TOOLS LISTS
2
MOTOROLA
MODEL NUMBER DESCRIPTION CHARACTERISTICS APPLICATION
R2000 Series System Analyzer This monitor will substitute Frequency/deviation meter and signal
for items with an asterisk (*) generator for wide-range
troubleshooting and alignment
R2600 Series System Analyzer This monitor will substitute Frequency/deviation meter and signal
for items with an asterisk (*) generator for wide-range
troubleshooting and alignment
*R1049A Digital Multimeter Digital voltmeter recommended
for ac/dc voltage and
current measurements
*R1150C Code Synthesizer Injection of audio and digital
signalling codes
*S1053D AC Voltmeter 1mV to 300V, 10-Megohm
*SKN6008A Power Cable for Meter input impedance Audio voltage measurements
*SKN6001A Test Leads for Meter
R1094A Dual-Trace 20MHz bandwidth Waveform measurements
Oscilloscope 5mV to 5V/division
*S1350C Watt Meter 50-ohm, ±5% accuracy Transmitter power output
*ST1213B (VHF) Plug-in Element 10 Watts, maximum measurements
*ST1223B (UHF) RF Dummy Load 0-1000MHz, 300W
R1065 Load Resistor 10-watt Broadband For use with Wattmeter
S1339A RF Millivolt Meter 100µV to 3V rf RF level measurements
10kHz to 1.2GHz
*R1013A SINAD Meter Receiver sensitivity
measurements
S1347D or DC Power Supply 0-20Vdc, 0-5 Amps Bench supply for 7.5Vdc
S1348D (programmable) current limited
*Any of the R2000/R2600 series system analyzers will substitute for items with an asterisk (*).
Table 40-1. Recommended Test Equipment
