NUD7070A, NUD7070B, NUD7085A, AND NUD7085B VHF TRANSCEIVER BOARDS’ PARTS LIST, AND
NUE7213A, NUE7213B, NUE7231B, NUE7240A, AND NUE7240B UHF (403-470MHz)
30 TRANSCEIVER BOARDS’ COMPONENT LOCATION DIAGRAMS
INSERT DIAGRAMS
(L1) BEPF-24636-O (20% BLK, 133 LINE)
(OL) BEPF-24637-O (100% BLK.)
R.T. 50%
INSERT DIAGRAMS
(L6) BEPF-24638-O (20% BLK., 133 LINE)
(OL) BEPF-24639-O (100% BLK.)
R.T. 50%
CAPACITOR, Fixed: pF ±5%;
50V unless stated
C4 2113741F13 330
C6 2113740F22 6.2 ± 0.25pF
C7 2113740F13 2.7 ± 0.25pF
C8 2113740F32 16
C9 - - - - - - - - - Not Placed
C11 2113741F49 .01µF
C12 - - - - - - - - - Not Placed
C13 2113741F49 .01µF
C14 2311049A66 22µF; 4V
C15 2113741F49 .01µF
C16 2113740F20 5.1 ± 0.25pF
C31 2113741F49 .01µF
C33 2113740F26 9.1
C34 2113740F43 47
C35 2113740F40 36
C36 2113740F19 0.47µF; ±0.25pF
C38 2113740F17 3.9µFl ±0.25pF
C39 0662057B47 0
C40 2113740F51 100
C41 2113743A19 0.1µF
C42 thru 46 2113743A23 0.22µF
C47 2109720D14 0.1µ F
C48 2113741F16 430
C49 2113743A19 0.1µF
C50 2113743K15 0.1µF
C52 2113741A51 0.18µF
C53 2113743B17 0.15µF
C54 2113741F13 330
C55 2113740F37 27
C56, 57 2113740F42 43
C58 2113740F11 2.2
C60 2113743K15 0.1µF
C61 2109720D14 0.1uF
C62 2113741F49 .01µF
C63 2113743K15 0.1µF
C65 2113741F49 .01µF
C70 2113741F49 .01µF
C71 thru 72 2113741F13 330
C77 2113743K15 0.1µF
C80 2113740F39 33
C82 thru 84 2113741F49 .01µF
C85 2311049A60 10µF; 4V
C86 2113740F22 6.2 ± 0.25pF
C87 2113740F32 16
C88 2113740F25 8.2 ± 0.25pF
C90 2113740F18 4.3 ±0.25pF
C95 2113740F33 18
C96 2113741F49 .01µF
C97 2113740A32 13
C98 2113741F13 330
C99 2113740F39 33
C101 2113743K15 0.1µF
C102 2113741F13 330
C103 2311049J26 10µF; 16V
C104 2311049A54 3.3µF; 16V
C105 2113741F13 330
C106 2311049J26 10µF; 16V
C107, 108 2113741F13 330
C109 2311049A07 1µF; 16V
C111 2113741F13 330
C112 - - - - - - - - - Not Placed
C113 2113741F13 330
C115 2113743K03 .033µF
C116 2113740F03 1.0±0.1pF
C118 2113743K15 0.1µF
C121 2113741F13 330
C123 2113743K15 0.1µF
C125, 126 2311049A54 3.3µ F; 16V
C128 2311049A07 1µF; 16V
C129 2113740F03 1
C130 2113740F28 11
C132 2113740F38 30
C133, 135 2113741F13 330
C139 - - - - - - - - - Not Placed
C140, 141, 146 2113741F13 330
C147 2113743E07 .022µF
C148 2113740F20 5.1 ± 0.25pF
C149, 150 2113740F34 20
C151 2113740F27 10
C152 2113741F13 330
C153 2113741F13 330
C154 2113741F13 330
C161 2113743K15 0.1µF
C162 2113741F13 330
C163 2113740F44 51
C164 2113740F51 100
C165 2311049A86 1.0µF; 10V
C202 2113740F27 10
C203 2113740F20 5.1 ± 0.25pF
C204 2113741F13 330
C205 2113740F14 3.0 ± 0.25pF
C206 2113741F20 620
C207 2113740F03 1.0 ± 0.1pF
C208 2113740F22 6.2 ± 0.25pF
C209 2113743K15 0.1µF
C210 2113743E07 .022µF
C211 2113741F13 330
C212 - - - - - - - - - Not Placed
C213 2113740F21 5.6 ± 0.25pF
C214 - - - - - - - - - Not Placed
C219 2113740F27 10
C220 2113740F31 15
C221 2113741F13 330
C222 2113740F24 7.5 ± 0.25pF
C223 2113906C02 ATC, 4pF
C225 2113740F08 1.6 ± 0.1pF
C226 2113740F46 62
C227, 228 2113741F13 330
C230 2113740F19 4.7 ± 0.25pF
C231 2311049A60 10µF; 4V
C233 2113741F13 330
C235 2113740F31 15
C236 2113740F27 10
C237 2113740F30 13
C238 2113741F25 .001µF
C240 2113906C02 ATC, 4pF
C241, 243 2113740F38 30
C244 2109720D09 .022µF
C245 2113741F25 .001µF
C246 2109720D09 .022µF
C247 2311049A07 1µF; 16V
C248 2113743K15 0.1µF
C250 2113741F25 .001µF
C251, 252 2113741F13 330
C253 2311049J23 10µF; 6V
C254 2311049A56 4.7µF; 10V
C255 2113741F25 .001µF
C256, 257 2113741F49 .01µF
C258 2311049J11 4.7µF; 16V
C259 2113743A23 0.22µF
C260 2113743K05 .039µF
C266, 267 2113741F49 .01µF
C270 2113741F25 .001µF
C271 2311049A56 4.7µF; 10V
C274 2113741F49 .01µF
C277 2113741F13 330
C280 2113740F51 100
C285, 286 2113741F13 330
C287 2113740F14 3.0 ± 0.25pF
C288 2113741F13 330
C291, 292 2113743E07 .022µ F
C293 - - - - - - - - - Not Placed
C294 2113741F13 330
C303 2113743E07 .022µF
C304 2113741F13 330
C305 thru 308 2113740F51 100
C309 2113741F37 .0033µF
C310 2113741F13 330
C311 2113741F37 .0033µF
C313, 314 - - - - - - - - - Not Placed
C315 2113741F13 330
DIODE:
CR1 thru 9 4862824C01 Varactor
CR11 4805129M96 PIN
CR12 4805218N57 Dual
CR102, 103 4805129M67 Dual
CR108, 109 4802482J02 PIN
CR201 4805649Q10 Varactor
CR202, 203 4805649Q08 Varactor
CR204, 205 4802233J09 Triple
CR206 4805129M06 Dual
CORE:
E101 2484657R01 Bead, Ferrite
F1 6505757V01 FUSE: 1-Amp.
FILTER:
FL1 4802655J05 Crystal, 44.85 MHz
JACK:
J301 - - - - - - - - - Circuit plating on NUD7070A
and NUD7085A; 20 contacts;
to P301 on Jumper Flex
or 0905461X01 Connector on NUD7070B
and NUD7085B; 20 contacts;
to P301 Strip Connector
J401 3905264W01 Contact, Antenna
and 3905643V01 Contact, Antenna Ground
COIL, RF:
L3 2462587T42 .047µH
L4 2462587T41 .039µH
L5 2462587T42 .047µH
L6 2462587T13 .068µH
L7 2462587T16 0.12µH
L8 2462587T17 0.15µH
L9 2462587T15 0.1µH
L10 2462587T12 .056µH
L11 2460591M12 4 turns, airwound
L12 2462587T23 0.47µH
L13, 14 2460591N36 5 turns, airwound
L16 2460591M12 4 turns, airwound
L19 2462587T20 0.27µH
L20 2462587N69 1.2µH
L22 2462587T30 1µH
L23 2462587Q50 1.8µH
L24 2462587T23 0.47µH
L25 2462587Q20 2.2µH
L30 2462575A21 .047µH
L32, 33 2462587Q20 2.2µH
L101 2462587T30 1µH
L105 2462587T30 1µH
L121, 122 2462587T30 1µH
L126 2460591K40 12 turns, airwound
L127 2460591G24 9 turns, airwound
L128 2460591K40 12 turns, airwound
L130, 131 2462587T30 1µH
L201 2462587T40 .033µH
L204 2462587T30 1µH
L205 2462587S28 .033µH
L208, 209 2462587T30 1µH
L210 2462587T39 .027µH
L211 2462587T12 .056µH
L212 2462587T15 0.1µH
L213, 215 2462587T30 1µH
L216 2462587T41 .039µH
L217, 218 2462587T30 1µH
L219 2462587T38 .022µH
L220 2462587T17 0.15µH
L221, 222 2462587Q42 0.39µH
L223 2462587T18 0.18µH
L225 2462587Q20 2.2µH
L301, 302 2462587Q47 1µH
PLUG:
P402 - - - - - - - - - Contact, External Antenna;
part of RF switch S101
P404 3905861X02 Connector, Battery; 2-pin
TRANSISTOR:
Q1, 4 4805218N63 NPN
Q101 4805128M16 PNP
Q104, 105, 107 4805921T02 PNP NPN
Q108 4802245J10 NPN Dual
Q110 4813822A10 PNP
Q201 4802245J15 JFET
Q202 4805218N55 NPN
RESISTOR, Fixed: Ω ±5%
.0625W unless stated
R1 0662057A01 10
R2 0662057A91 56k
R4, 5 0662057A73 10k
R7 0662057A25 100
R8 0662057A41 470
R16 0662057A59 2.7k
R17 0662057A80 20k
R32, 33 0662057A59 2.7k
R34. 35 0662057A89 47k
R40 0662057A35 270
R41 0662057A09 22
R42 0662057A35 270
R43 0662057A42 510
R44 0662057A77 15k
R45 0660257B47 0
R46 0662057A89 47k
R47 0662057A09 22
R49 0662057A53 1.5k
R50 0662057A63 3.9k
R51 0662057B05 200k
R70 0662057A53 1.5k
R72 0662057A25 100
R73 0662057A73 10k
R101 0662057C01 0
R102 0662057A65 4.7k
R106 0662057A61 3.3k
R110 0662057A57 2.2k
R111 0662057A67 5.6k
R112 0662057B22 1 M
R113 0662057A73 10k
R114 0662057A77 15k
R115 0660078L28 180k ± 1%
R116 0662057G19 130k ± 1%; 0.1W
R117 0662057A89 47k
R126 0662057A18 51
R127 0662057A15 39
R130 0662057A65 4.7k
R131, 132 0662057A97 100k
R199 0660257B47 0; used in place of S101 in
NUD7085A and NUD7085B
or - - - - - - - - - Not Used, replaced with S101
in NUD7070A and NUD7070B
R203 0662057A09 22
R204 0662057A80 20k
R205 0662057A84 30k
R206, 207 0662057A80 20k
R208 0662057A62 3.6k
R209, 210 0662057A42 510
R211 0662057A20 62
R212 0662057A44 620
R213 0662057A41 470
R214 0662057A88 43k
R215 0662057A84 30k
R217 0662057A84 30k
R218 0662057A97 100k
R219 0662057A09 22
R220, 221 0662057A56 2k
R222 0662057A51 1.2k
R223 0662057A89 47k
THERMISTOR:
RT101 0605621T02 Thermistor, 50k
SWITCH:
S101 4005831W01 RF; used on NUD7070A and
NUD7070B
or - - - - - - - - - Not Used, replaced with R199
on NUD7085A and
NUD7085B
TRANSFORMER:
T1 2505515V08 Balun; 4:1
T2 2505515V11 Balun; 16:1
MODULES:
U1 5105329V20 RF Amp
U2 5105329V26 Mixer
U3 5105457W11 IF
U101 5105662U72 TX ALC
U102 5105662U70 D/A
U103 5160880B02 5V Regulator
U104 5102001J69 Stripline Coupler
U105 5105625U03 5-Watt PA
U201 5105662U78 VCO
U202 5105469E65 5V Regulator
U203 5105279V39 Ref. Oscillator, 16.8 MHz
U204 5105625U31 Synthesizer
Electrical Parts List, VHF Transceiver Boards; VHF
NUD7070A, NUD7070B
NUD7085A, NUD7085B
TPLF- 4072-C
REFERENCE MOTOROLA
SYMBOL PART NO. DESCRIPTION
Note: "Not Placed" means that components are for future use, and are not
placed on the circuit board at this time.
