Motorola HT 1000 Series - Keypad Radio Exploded View Diagram and Parts List

KEYPAD RADIO EXPLODED VIEW DIAGRAM AND PARTS LIST 47
Keypad Radio Exploded View Parts List TPLF-4085-D
ITEM MOTOROLA
NO. PART NO. DESCRIPTION
1 4505896U01 LEVER, PTT
2 3205902U01 SEAL, PTT, and ACTUATOR for S404,
S405, S406, and S408
3A 1505637V01 COVER, Front; Full Keypad
3B 1505637V02 COVER, Front; Limited Keypad
4 - - - - - - - - - LABEL, Agency Approval; not field
replaceable
5A 7505870U01 KEYPAD, 15-key
5B 7505870U02 KEYPAD, 6-key
6 5105238U83 MODULE, Display
7 3305183R55 LABEL, Motorola
8 3305183R70 LABEL, MT2000
or 3305183R71 LABEL, MTS2000
or 3305183R94 LABEL, MTX
9 3505535X02 FELT, Speaker
10 See Note 1 SPEAKER (LS401)
11 0705470V01 BRACKET, Speaker Retainer
12 See Note 1 MICROPHONE (MK401)
13 1405330W02 BOOT, Microphone
14 8405310W01 FLEX, Front Cover/Display
15 8405151Y01 FLEX, Controls
16 3905517V01 POPPLE, PTT (p/o S406)
17 3605253V01 KNOB, On/Off/Volume
18 3605636V01 KNOB, Frequency
19 1305633V01 RING, Concentric; Escutcheon
20 3605635V01 KNOB, Concentric Ring
21 1305698V01 ESCUTCHEON, Control Top
22 3205160W01 SEAL, Actuator; for S101
Notes:
1. Refer to electrical parts list (miscellaneous) for part number and com-
plete description.
2. Refer to electrical parts list (transceiver board) for part number and com-
plete description.
23 2205159W01 PIN, Actuator; for S101
24 3205514W01 SEAL, Accessory Connector
25 3205292W01 SEAL, Control Top
26 3205293W01 SEAL, Emergency Button
27 2705877U01 HOUSING, Switch
28 See Note 1 SWITCH, Toggle (S402)
29 See Note 1 POTENTIOMETER/SWITCH,
On/Off/Volume Control (R401/S403)
30 3905329W01 POPPLE, Emergency Button
31 See Note 1 LED (CR702A/CR702B)
32 See Note 1 SWITCH, Frequency (S401)
33 1505632V01 COVER, Switch Housing
34 - - - - - - - - - SPRING, PA; not field replaceable, order
front shield (item 41)
35 4205507X01 STRAIN RELIEF
36 See Note 1 CONNECTOR, Strip (P301/P704)
or 8405247V01 FLEX, Jumper (early version radios)
37 See Note 2 PLUG, Connector (P404)
38 3205820V02 SEAL, Connector Plug
39 - - - - - - - - - LABEL, Rear; Information;
not field replaceable
40 3205126W01 O-RING, Contoured/SEAL, Antenna
41 2605891U02 SHIELD, Front
42 See Note 1 SWITCH, RF (S101)
43 - - - - - - - - - LABEL, Barcode; not field replaceable
44 4105266V01 SPRING, RF Switch
45 4405524V01 PISTON, RF Switch
46 1405307X01 INSULATOR
47 1505892U01 CHASSIS (Rear Cover)
48 3905838V01 CONTACT, Antenna Shield Ground
(800MHz and 900MHz radios only)
49 2605898U01 SHIELD, PA (800MHz and 900MHz radios
only)
50 7505393N33 PAD, Shock
INSERT EXPLODED VIEW
CEPF-22751-C
