CAPACITOR, Fixed: pF ±5%;
50V unless stated
C601 2113743A19 0.1µF
C602, 603, 604 2113741A33 3.3nF
C605, 606 2113743K15 0.1µF
C607 2113743A23 0.22µF
C608 2113743A19 0.1µF
C609, 610 2311049A04 0.33µF
C611, 612 2311049A42 3.3µF
C613 2113741F17 470
C614 2113741F49 10nF
C615 2113741F17 470
C616 2113743K15 0.1µF
C617 2113741M53 .022µF
C618 2113743A19 0.1µF
C619 2113741F49 10nF
C620 2113741M53 .022µF
C700 thru 708 2113741F17 470
C709 2113743A23 0.22µF
C710 2311049J11 4.7µF
C711 2311049A07 1.0µF
C712, 713 2113743A19 0.1µF
C714, 715 2113743K15 0.1µF
C716, 717 2113743A23 0.22µF
C718 2113743K15 0.1µF
C719 2311049A01 0.1µF
C720 2113741F49 10nF
C721 2113743K15 0.1µF
C722 2311049A09 2.2µF
C723 2113743A23 0.22µF
C724 2113740F36 24
C725 2311049A07 1µF
C726 2113743F12 0.33µF
C727 2311049A07 1µF
C728 2113743F12 0.33µF
C729 2311049A07 1µF
C730 2113741F41 4.7nF
C731 2113743K15 0.1µF
C732 2311049J11 4.7µF
C733 2113743K15 0.1µF
C734 2311049J23 10µF
C735 thru 738 2113741F17 470
C739 2113740F39 33
C740, 741, 742 2113741F17 470
C743 2113741A49 15nF
C744 2113741F49 15nF
C745 2113740F39 33
C746 thru 757 2113741F17 470
C758 2113743K15 0.1µF
C759, 760, 761 2113741F17 470
C762 2113743K15 0.1µF
C763, 764 2113740F36 24
C765 2113743K15 0.1µF
C766 2311049A42 3.3µF
C767 2113743K15 0.1µF
C768 2113741F49 10nF
C769 2113741F17 470
C770 2311049J23 10µF
C771 2113743K15 0.1µF
C772 2311049A42 3.3µF
C773 2113743A19 0.1µF
C774, 775 2113741F17 470
C776 2113743K15 0.1µF
C777 2311049A07 1µF
C778 2113743K15 0.1µF
C779 - - - - - - - - - Not Placed
C780 thru 786 2113741F17 470
C787 2113740F39 33
C788 thru 791 2113741F17 470
C792 2113741F13 330
C793 2113743A19 0.1µF
C795 2113740F39 33
C796 2311049A07 1.0µF
C797 2113740F51 100
C798 2113741F49 10nF
C804 2113741F41 4700
C808 2113741F41 4700
Electrical Parts List, Controller TPLF-4206-A
NTN7512A Front Display VHF, UHF, and 800MHz Radios
NTN7513A Front Display 900MHz Hear Clear Radios
NTN7857A Top/No Display VHF, UHF, and 800MHz Radios
NTN7858A Top/No Display 900MHz Hear Clear Radios
DIODE:
CR701 4880236E05 Schottky
CR702, 703, 704 4805218N57 Dual
CR705 4813833C02 Dual
CR706 4805218N57 Dual
JACK:
J701 0905257V04 Connector, 26-pin; to P701 on
Front Cover Display Flex
J702 0913915A11 Connector, 25-pin
J703 0905257V03 Connector, 18-pin; to P703 on
Controls Flex
J704 - - - - - - - - - - Circuit Plating on early ver-
sion radios, 20 contacts; to P704
on Jumper Flex
or 0905461X01 Connector on later version
radios, 20 contacts; to P704
Strip Connector
L702 thru 706 2462587Q40 COIL, RF: 270 nH
TRANISITOR:
Q701 4805128M40 PNP
Q703 4880048M01 NPN
RESISTOR, Fixed: Ω ±5%;
.0625W unless stated
R601 0662057G13 100k
R602 0662057A53 1.5k
R603 0662057R60 10k
R604 0662057R30 1k
R605 0662057A97 100k
R606 0662057R92 47.5k
R607 0662057G13 100k
R608 0662057A81 22k
R700 0662057A65 4.7k
R701 0662057A56 2k
R702 0662057A81 22k
R703 0662057A56 2k
R704 0662057A41 470
R705 0662057R92 47.5k
R706 0662057A56 2k
R707 0662057A41 470
R708 0662057A56 2k
R710 0662057A89 47k
R711 0662057A97 100k
R712 0662057A56 2k
R713 0662057A81 22k
R714 0683962T45 68
R715 0662057A97 100k
R716, 717 0662057A81 22k
R718 0662057A97 100k
R719 0662057B02 150k
R720, 721, 722 0662057A89 47k
R723 0662057A49 1k
R724 0662057A89 47k
R725 0662057G07 75k
R726 0662057G08 82.5k
R727 0662057A81 22k
R728, 729 0662057A89 47k
R730, 731 0662057C55 150
R732 0662057A73 10k
R736 0662057A81 22k
R738 0662057A81 22k
R739 0662057A73 10k
R740, 741 0662057A81 22k
R743 0662057A73 10k
R746 0662057A97 100k
R747 0662057B02 150k
R749 0662057A73 10k
R750 0662057A97 100k
R754 0662057B47 0
R757 0662057A81 22k
R758 0662057A97 100k
R759 0662057A81 22k
R761 0662057A73 10k
R801 0660076E56 2k
R802, 803 0660257A56 2k
MODULE:
U601 5105662U60 Hear Clear
U701 5105663U42 Audio Signalling Filter
U702 5105662U62 Audio PA
U703 4805921T09 Dual Transistor
U704 4805921T07 Transistor, NPN
U705 5105662U52 Microcomputer
U708 5105469E65 5V Regulator
U709 5105750U28 Mux
U710 5105750U31 SLIC IV
REFERENCE MOTOROLA
SYMBOL PART NO. DESCRIPTION
U711 5184704M60 Multiplexer
U712 4805718V01 Transistor Package
U713 5105662U58 EEPROM
U714 5105662U54 SCRAM
U715 5105318X01 256 x 8 Masked ROM (for all
keypad radios)
or 5105318X02 256 x 8 Masked ROM (for no
display and top display radios)
DIODE, Zener:
VR701, 702 4813830A23 10V
VR703 4813830A18 6.8V
VR704 thru 711 4880140L09 6.2V
VR712 4805718V01 20V
VR713 4813830A23 10V
VR714 4813830A18 6.8V
VR715 4813830A14 5.1V
VR717 4813830A27 14V
VR718 4880140L09 6.2V
Notes:
1. 600 Series HearClear components are part of NTN7513A and
NTN7858A.
2. “Not Placed” means that components are for future use, and are not
placed on the circuit board at this time
NTN7512A, NTN7513A, NTN7857A, AND NTN7858A CONTROLLER BOARDS’ PARTS LIST,
BASIC RADIO EXPLODED VIEW DIAGRAM, TOP-DISPLAY EXPLODED VIEW DIAGRAM,
46 AND PARTS LIST
INSERT EXPLODED VIEW
CEPF-22595-D
1 4505896U01 LEVER, PTT
2 3205902U01 SEAL, PTT, and ACTUATOR for S404,
S405, S406, and S408
3A 1505627V01 COVER, Front
3B or 1505637V03 COVER, Front; DTMF
4 - - - - - - - - - - LABEL, Agency Approval; not field
replaceable
5 3305183R55 LABEL, Motorola
6 3305183R56 LABEL, HT1000
7 3505535X02 FELT, Speaker
8 See Note 1 SPEAKER (LS401)
9 0705470V01 BRACKET, Speaker Retainer
10 See Note 1 MICROPHONE (MK401)
11 1405330W01 BOOT, Microphone
12 8405310W01 FLEX, Front Cover/Display
13 8405151Y01 FLEX, Controls
14 3905517V01 POPPLE, PTT (p/o S406)
15 3605253V01 KNOB, On/Off/Volume
16 KNOB, Frequency
3605254V02 2-Frequency Radios
or 3605254V01 16-Frequency Radios
17 ESCUTCHEON, Control Top
1305872V02 2-Frequency Radios
or 1305872V01 16-Frequency Radios
18 3205160W01 SEAL, Actuator; for S101
19 2205159W01 PIN, Actuator; for S101
20 3205514W01 SEAL, Accessory Connector
21 3205292W01 SEAL, Control Top
22 3205293W01 SEAL, Emergency Button
23 2705877U01 HOUSING, Switch
24 See Note 1 SWITCH, Toggle (S402)
25 See Note 1 POTENTIOMETER/SWITCH,
On/Off/Volume Control (R401/S403)
26 3905329W01 POPPLE, Emergency Button
27 See Note 1 LED (CR702A/CR702B)
28 See Note 1 SWITCH, Frequency (S401)
29 1505632V01 COVER, Switch Housing
30 - - - - - - - - - - SPRING, PA; not field replaceable, order
front shield (item 37)
31 4205507X01 STRAIN RELIEF
32 See Note 1 CONNECTOR,Strip (P301/P704)
or 8405247V02 FLEX, Jumper (early version radios)
33 See Note 2 PLUG, Connector (P404)
34 3205820V02 SEAL, Connector Plug
35 - - - - - - - - - - LABEL, Rear; Information; not field
replaceable
36 3205126W01 O-RING, Contoured/SEAL, Antenna
37 2605891U01 SHIELD, Front
38 See Note 1 SWITCH, RF (S101)
39 - - - - - - - - - - LABEL, Barcode; not field replaceable
40 4105266V01 SPRING, RF Switch
41 4405524V01 PISTON, RF Switch
42 1405307X01 INSULATOR
43 1505892U01 CHASSIS (Rear Cover)
44 3905838V01 CONTACT, Antenna Shield Ground
(800MHz and 900MHz radios only)
45 2605898U01 SHIELD, PA (800MHz and 900MHz radios
only)
46 7505334W01 PAD, Sound Dampening
47 7505437W01 KEYPAD, DTMF
48 5102463J08 CIRCUIT BOARD, DTMF
49 7505393N33 PAD, Shock
Basic Radio Exploded View Parts List TPLF-4075-D
ITEM MOTOROLA
NO. PART NO. DESCRIPTION
INSERT EXPLODED VIEW
CEPF-23261-A
1 4505896U01 LEVER, PTT
2 3205902U01 SEAL, PTT, and ACTUATOR for S404,
S405, S406, and S408
3 1505627V02 COVER, Front
4 - - - - - - - - - LABEL, Agency Approval; not field
replaceable
5 3305183R55 LABEL, Motorola
6 3305183R70 LABEL, MT2000
or 3305183R71 LABEL, MTS2000
or 3305183R94 LABEL, MTX
7 3505535X02 FELT, Speaker
8 See Note 1 SPEAKER (LS401)
9 0705470V01 BRACKET, Speaker Retainer
10 See Note 1 MICROPHONE (MK401)
11 1405330W02 BOOT, Microphone
12 8405641V01 FLEX, Front Cover/Display
13 8405151Y01 FLEX, Controls
14 3905517V01 POPPLE, PTT (p/o S406)
15 3605253V01 KNOB, On/Off/Volume
16 3605636V01 KNOB, Frequency
17 1305698V01 ESCUTCHEON, Control Top
18 3205160W01 SEAL, Actuator; for S101
19 2205159W01 PIN, Actuator; for S101
20 3205514W01 SEAL, Accessory Connector
21 3205292W01 SEAL, Control Top
22 3205293W01 SEAL, Emergency Button
23 2705877U01 HOUSING, Switch
24 See Note 1 SWITCH, Toggle (S402)
25 See Note 1 POTENTIOMETER/SWITCH,
On/Off/Volume Control (R401/S403)
26 3905329W01 POPPLE, Emergency Button
27 See Note 1 LED (CR702A/CR702B)
28 See Note 1 SWITCH, Frequency (S401)
29 1505632V01 COVER, Switch Housing
30 - - - - - - - - - SPRING, PA; not field replaceable, order
front shield (item 37)
31 4205507X01 STRAIN RELIEF
32 See Note 1 CONNECTOR,Strip (P301/P704)
or 8405247V01 FLEX, Jumper (early version radios)
33 See Note 2 PLUG, Connector (P404)
34 3205820V02 SEAL, Connector Plug
35 - - - - - - - - - LABEL, Rear; Information; not field
replaceable
36 3205126W01 O-RING, Contoured/SEAL, Antenna
37 2605891U02 SHIELD, Front
38 See Note 1 SWITCH, RF (S101)
39 - - - - - - - - - LABEL, Barcode; not field replaceable
40 4105266V01 SPRING, RF Switch; part of item 39
41 4405524V01 PISTON, RF Switch; part of item 39
42 1405307X01 INSULATOR
43 1505892U01 CHASSIS (Rear Cover)
44 3905838V01 CONTACT, Antenna Shield Ground
(800MHz and 900MHz radios only)
45 2605898U01 SHIELD, PA (800MHz and 900MHz radios
only)
46 7505334W01 PAD, Sound Dampening
47 Not Used
48 Not Used
49 7505393N33 PAD, Shock
50 1305633V01 RING. Concentric; Escutcheon
51 3605635V01 KNOB, Concentric Ring
52 5105238U82 LCD, Top Display
Top-Display Exploded View Parts List TPLF-4154-A
ITEM MOTOROLA
NO. PART NO. DESCRIPTION
Notes:
1. Refer to electrical parts list (miscellaneous) for part number and complete description.
2. Refer to electrical parts list (transceiver board) for part number and complete description.
Notes:
1. Refer to electrical parts list (miscellaneous) for part number and complete description.
2. Refer to electrical parts list (transceiver board) for part number and complete description.
