Motorola L6 User Manual

16 October 14, 2005 6809495A75-O
Tools and Test Equipment L6
Tools and Test Equipment
Table 1 lists the tools and test equipment used on L6 telephones. Use either the
listed items or equivalents.
Table 1. General Test Equipment and Tools
Motorola
Part Number
1
Description Application
See Table 6. Charger Used to charge battery and power phone.
0180386A82
Antistatic Mat Kit (includes 66-80387A95 antistatic
mat, 66-80334B36 ground cord, and 42-80385A59
wrist band)
Provides protection from damage to phone caused
by electrostatic discharge (ESD).
6680388B67 Disassembly Tool, plastic with flat and pointed
ends (manual opening tool)
Used during assembly/disassembly.
6680388B01 Tweezers, plastic Used during assembly/disassembly.
RSX4043-A Torque Driver Used to remove and replace screws.
— Torque Driver Bit T-5 Plus Used with torque driver.
HP34401A
2
Digital Multimeter Used to measure battery voltage.
W.FL2-LP-N Coaxial cable connector extraction tool
Used to remove cable connector from circuit
board.
W.FL-LP-IN Coaxial cable connector insertion tool Used to attach cable connector to circuit board.
1. To order in North America, contact Motorola Aftermarket and Accessories Division (AAD) by phone at (800) 422-4210 or
FAX (800) 622-6210; Internationally, you can reach AAD by phone at (847) 538-8023 FAX (847) 576-3023.
2. Not available from Motorola. To order, contact Hewlett Packard at (800) 452-4844.
1 and 2
6809495A75-O
L6

Motorola L6 Specifications

General

Display Size	1.8 inches
Resolution	128 x 160 pixels
Internal Storage	10 MB
Main Camera	VGA
Dimensions	113 x 49 x 10.9 mm (4.45 x 1.93 x 0.43 in)
Weight	86 g (3.03 oz)
Network Technology	GSM
2G bands	GSM 850 / 900 / 1800 / 1900
GPRS	Class 10
EDGE	Class 10
Announced	2005, Q4
Status	Discontinued
SIM	Mini-SIM
Memory Card slot	No
Phonebook	1000 entries
Video	Yes
Alert types	Vibration; Downloadable polyphonic, MP3 ringtones
Loudspeaker	Yes
3.5mm jack	No
WLAN	No
Radio	No
Browser	WAP 2.0/xHTML
Games	Yes + downloadable
Java	Yes, MIDP 2.0
Bluetooth	v1.2
Messaging	SMS, EMS, MMS
Colors	Black, Silver, Pink, Blue
OS	Proprietary
